SET DATA : Press to specify the sequence number. LEVEL SET : Press to specify the block skip mark contrast. SET SIZE : Press to specify the block skip mark size. DSP REAL IMG : Press to display the current image at the s…
Use the numerical keypad to specify the sequence number of a fiducial mark sequence in the
current production program.
When the START button is pressed, the X-axis and the Y table move so that the specified fiducial
mark is under the mark camera. An image of the mark is acquired and inspected. Data describing
the fiducial mark displays on the vision processing monitor. An error occurs if there is no board on
the Y-table.
Chapter 3 Description of Commands
Part 3
3 - 54
Version 2.0 GL-541E Operation
TEST IMAGE
Sequence 2
Pattern 0
B/W White
Size_a 1.23[mm]
Size_b 1.23[mm]
Size_c 1.23[mm]
Scan 500[um]
Result X: -123[um]
Y: 123[um]
Error: 12345678
F MARK Inspecting a Fiducial Mark 522-421
FUJI
Off line
Page 522
Command path:
GL_541E Prod 0000 Sche 00000
F MARK
Sequence no.?
[SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [SET DATA]
• Explanation
SET DATA : Press to specify the sequence number.
LEVEL SET : Press to specify the block skip mark contrast.
SET SIZE : Press to specify the block skip mark size.
DSP REAL IMG : Press to display the current image at the selected camera (only for mark
cameras).
VP. EXE : Press to carry out vision processing.
RETURN : Press to return to Page 522-430.
Chapter 3 Description of Commands
Part 3
3 - 55
Version 2.0 GL-541E Operation
TEST IMAGE
Sequence 2
Pattern White
Level 128
Size_x 1.23[mm]
Size_y 1.23[mm]
Result White
Error: 12345678
B MARK Inspecting a Block Skip Mark 522-430
FUJI
Off line
Page 522
RETURNVP EXEDSP REAL IMAGESET SIZELEVEL SETSET DATA
Command path:
GL_541E Prod 0000 Sche 00000
B MARK
Ready
[SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK]
• Action of the function keys
Chapter 3 Description of Commands
Part 3
3 - 56
Version 2.0 GL-541E Operation
• Explanation
Press [SET DATA] to specify the sequence number of the block skip mark which will be inspected.
The [LEVEL SET] command sets the contrast (border value) of the block skip mark.
Press [SET SIZE] to display the screen at which the block skip mark size can be set.
The [DSP REAL IMG] command displays the real image obtained by the mark camera on the vision
processing monitor. This command cannot be executed unless the F1 command (SET DATA) has
already been executed. When the command is executed, the message “Specify mark sequence
number” displays in the first display area.
Press [VP. EXE.] to inspect the specified block skip mark (sequence number). This command
cannot be executed unless the F1 command (SET DATA) has already been executed. When the
command is executed, the message “Specify mark sequence number” displays in the first display
area.
Note: The previous two commands are only available after the [SET DATA] command has been executed.
If the [SET DATA] command has not been executed, a message to that extent will appear in the first
display area.
• Explanation of the Items displayed
B/W : B mark B/W type (white or black)
Level : B mark threshold level (0~255)
Size_x : B mark size [0.01 mm]
Size_y : B mark size [0.01 mm]
Result : Result of vision processing (white or black)
Error : Error code.
