Appendix A Chapter 1 Input Port Display V ersion 2.0 A - 1 1 LX020 ID DECEL PNT1 MCID speed reduction point LX021 ID ARRV CHK1 MCID board arrival LX022 ID DECEL PNT2 MCID reverse speed reduction point LX023 ID ARRV CHK2 …
Appendix A
Chapter 1 Input Port Display
A - 10Version 2.0
LX010 WAIT PCB OUT WAIT signal
LX011 (MCID CONV) MCID conveyor installed (option)
LX012 (SPINE CONV) SPINE conveyor installed (option)
LX013
LX014
LX015
LX016
LX017
LX018
LX019
LX01A
LX01B
LX01C
LX01D
LX01E
LX01F
LED No. Display Description
Board Loader PLC Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 11
LX020 ID DECEL PNT1 MCID speed reduction point
LX021 ID ARRV CHK1 MCID board arrival
LX022 ID DECEL PNT2 MCID reverse speed reduction point
LX023 ID ARRV CHK2 MCID reverse board arrival check
LX024 ID W. CONV +OT MCID conveyor overtravel (+)
LX025 ID W. CONV -OT MCID conveyor overtravel (-)
LX026 ID INCHING + MCID inching (+)
LX027 ID INCHING - MCID inching (-)
LX028 ID +FOLLOW CHK MCID follow check (wide)
LX029 ID -FOLLOW CHK MCID follow check (narrow)
LX02A ID STPR1 ON MCID stopper on
LX02B ID STPR1 OFF MCID stopper off
LX02C ID STPR2 ON MCID reverse stopper on
LX02D ID STPR2 OFF MCID reverse stopper off
LX02E ID PCB TRAN MCID board transfer check
LX02F FOLLOW PERMIT Follow permission (option)
LED No. Display Description
Board Loader PLC Input 2
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 12Version 2.0
LX030 +FOLLOW CHK Follow check (wide)
LX031 -FOLLOW CHK Follow check (narrow)
LX032
LX033
LX034
LX035
LX036
LX037
LX038 Select IP-type conveyor
LX039 PCB FEEDER ADV Board pusher at forward limit (SPINE)
LX03A PCB FEEDER RET Board pusher at retract limit (SPINE)
LX03B PASS CHECK1 Board transit check 1
(main conveyor/SPINE)
LX03C PASS CHECK2 Board transit check 2
(magazine loader/SPINE)
LX03D SPINE CONV UP Lifter conveyor at upper limit (SPINE)
LX03E SPINE CONV DWN Lifter conveyor at lower limit (SPINE)
LX03F INTERLOCK Interlock from magazine loader (SPINE)
LED No. Display Description
Board Loader PLC Input 2
GL-541E Operation
