B/W SET : Press to specify the B/W contrast of the glue. LEVEL SET : Press to specify the range of the camera. RETURN : Press to return to Page 523. Chapter 3 Description of Commands Part 3 3 - 67 V ersion 2.0 GL-541E Op…
SET : Press to measure the glue check reference data for the Z3 syringe.
RETURN : Press to return to Page 523.
• Explanation
Before pressing the [SET] key, position the camera over the relevant glue dot.
Chapter 3 Description of Commands
Part 3
3 - 66
Version 2.0 GL-541E Operation
Ref. data : 2000 [Um
2
]
Z3 Setting Reference Data for the Z2 Syringe 523-230
FUJI
Off line
Page 523
RETURNSET
Command path:
GL_541E Prod 0000 Sche 00000
Z3
G.ref.[%] =
[SET] - [MANUAL] - [GLUE] - [SET] - [Z3]
• Action of the function keys
B/W SET : Press to specify the B/W contrast of the glue.
LEVEL SET : Press to specify the range of the camera.
RETURN : Press to return to Page 523.
Chapter 3 Description of Commands
Part 3
3 - 67
Version 2.0 GL-541E Operation
GLUE DATA
Glue B/W block
Glue Scan Area 120
SET DATA Setting the Glue Data 523-300
FUJI
Off line
Page 523
RETURNLEVEL SETB/W SET
Command path:
GL_541E Prod 0000 Sche 00000
SET DATA
Color (or Level)
[SET] - [MANUAL] - [GLUE] - [SET DATA]
• Action of the function keys
Z1 : Press to select the Z1 syringe.
Z2 : Press to select the Z2 syringe.
Z3 : Press to select the Z3 syringe.
RETURN : Press to return to Page 520.
• Explanation
This command carries out compensation of the center coordinates of the needle rotational axis and
the needle tip. It also specifies which needle will perform glue application.
Chapter 3 Description of Commands
Part 3
3 - 68
Version 2.0 GL-541E Operation
NEEDLE Measuring Needle Offset 524
FUJI
Off line
Page 524
RETURNZ3Z2Z1
Command path:
GL_541E Prod 0000 Sche 00000
NEEDLE
[SET] - [MANUAL] - [NEEDLE]
• Action of the function keys
