REMOTE : Press this key to check the inputs and outputs assigned to the machine. SEQUENCER : Press this key to check the inputs and outputs assigned to the sequence loader. OPLINK : Press this key to check the inputs and…
I/O : Press to check the input and output signals.
VISION : Press to make settings for the vision system.
G : Press to set G data and air pressure.
NEEDLE : Press to measure needle offset. This command cannot be used
unless zero setting has been completed.
MEMORY : Press to display the contents of the machine’s internal memory.
RETURN : Press to return to Page 500/000.
Chapter 3 Description of Commands
521
522
523
524
525
500
Part 3
3 - 39
Version 2.0 GL-541E Operation
MANUAL Setting and Checking Inputs and Outputs 520
FUJI
Off line
Page 520
RETURNMEMORYNEEDLEGVISIONI/O
Command path:
GL_541E Prod 0000 Sche 00000
MANUAL
[SET] - [ MANUAL]
• Action of the function keys To page
REMOTE : Press this key to check the inputs and outputs assigned to
the machine.
SEQUENCER : Press this key to check the inputs and outputs assigned to
the sequence loader.
OPLINK : Press this key to check the inputs and outputs of the
internal support relay.
SERVO : Press this key to check the inputs and outputs of the servo
board.
RETURN : Press to return to page 520.
Chapter 3 Description of Commands
521-100
521-000
521-100
Part 3
3 - 40
Version 2.0 GL-541E Operation
I/O Checking the Inputs and Outputs 521-000
FUJI
Off line
Page 521
RETURNSERVOOPLINKSEQUENCERREMOTE
Command path:
GL_541E Prod 0000 Sche 00000
I/O CHECK
[SET] - [MANUAL] - [I/O]
• Action of the function keys To page
IN : Press to check the input signals.
OUT : Press to check the output signals.
RETURN : Press to return to Page 520/000.
• Explanation
“NAME” in the above display indicates the name of the input/output signal.
“I” in the above display indicates whether the signal is on or off.
O = on, X = off
Chapter 3 Description of Commands
521-110
521-120
521
Part 3
3 - 41
Version 2.0 GL-541E Operation
IN PORT OUT PORT
NO I NAME NO I NAME
X000 0 EMERGENCY SW Y000 X START LAMP
X001 X START SW Y001 X RESET LAMP
X002 X RESET SW Y002 X BUZZER
X003 X CYCLE STOP SW Y003 X
X004 X Y004 X
X005 X Y005 X SERVO ON
X006 X Y006 X OTVL CUT
X007 X Y007 X FIDUCIAL
REMOTE Checking the Input and Outputs 521-100
FUJI
Off line
Page 521
RETURNOUTIN
Command path:
GL_541E Prod 0000 Sche 00000
IO CHECK
I/O Check
[SET] - [MANUAL] - [I/O] - [REMOTE]
• Action of the function keys To page
