MARK CAMERA : Press to measure the mark camera Proper data. X0/Y0 : Press to measure the X and Y-coordinates of the reference pin. XC/YC : Press to measure the X and Y-coordinates of the nozzle center. Z0 : Press to meas…
FUNCTION 9~12 : Presently not supported.
ETC. MODE : Press to return to Page DBG.
RETURN : Press to return to Page 520/000.
Chapter 3 Description of Commands
DBG
520
Part 3
3 - 84
Version 2.0 GL-541E Operation
MEMORY Displaying the Memory Contents DBG-5-5
FUJI
Off line
Page DBG-5-5
RETURNECT. MODEFUNCTION 12FUNCTION 11FUNCTION 10FUNCTION 9
Command path:
GL_541E Prod 0000 Sche 00000
MEMORY
[SET] - [MANUAL] - [MEMORY] - [ETC. MODE] - [ECT. MODE]
• Action of the function keys To page
MARK CAMERA : Press to measure the mark camera Proper data.
X0/Y0 : Press to measure the X and Y-coordinates of the reference
pin.
XC/YC : Press to measure the X and Y-coordinates of the nozzle
center.
Z0 : Press to measure the Z-axis coordinate when the nozzle is
making contact with the surface of the board.
LOAD PSTN : Press to measure the coordinates of the Y-axis when the
loader is connected.
RETURN : Press to return to Page 500.
• Input from numerical keypad
Using the numerical keypad input the ID code set in Proper data.
Chapter 3 Description of Commands
531
532
533
534
535
500
Part 3
3 - 85
Version 2.0 GL-541E Operation
Proper
X0 : 15710 Y0 : 621
Xc_1 : 7038 Yc_1 : -1708
Xc_2 : 13540 Yc_2 : -1706
Xc_3 : 8040 Yc_3 : -1710
Z0_1 : 283
Z0_2 : 254
Z0_3 : 265
Xc_1 : 8735
PROPER Measuring Proper Data 530
FUJI
Off line
Page 530
RETURNLOAD PSTNZ0XC/YCX0Y0MARK CAMERA
Command path:
GL_541E Prod 0000 Sche 00000
PROPER
id code?
[SET] - [PROPER]
• Action of the function keys To page
SET : Press to enable the START button. When the START button is
pressed, the machine will measure the Proper data for the camera
and return to page 530.
RETURN : Press to return to Page 530.
Chapter 3 Description of Commands
530
530
Part 3
3 - 86
Version 2.0 GL-541E Operation
Resolution X 0000000
Resolution Y 0000000
Delta X 0000000
000.000 [mm]
Delta Y 0000000
000.000 [mm]
Delta Q 0000000
000.000 [mm]
CAMERA Measuring the Camera Proper Data 531
FUJI
Off line
Page 531
RETURNSET
Command path:
GL_541E Prod 0000 Sche 00000
CAMERA
[SET] - [PROPER] - [MARK CAMERA]
• Action of the function keys To page
