Z1 : Press to select the Z1 syringe. Z2 : Press to select the Z2 syringe. Z3 : Press to select the Z3 syringe. RETURN : Press to return to Page 523. Chapter 3 Description of Commands Part 3 3 - 63 V ersion 2.0 GL-541E Op…

100%1 / 261
Use the ▲ and ▼ keys to select the desired application time or air pressure.
▲ : Press to move the cursor up one line.
▼ : Press to move the cursor down one line.
RETURN : Press to return to Page 523.
• Input from numerical keypad
Input the required values from the numerical keypad.
Input the glue application time (G data column of the application sequence) as a coefficient [%] in
the range from 1 to 999%.
Input the glue application pressure as a coefficient of the supply air pressure (5 kg/cm) in the range
from 1 to 100%.
Chapter 3 Description of Commands
Part 3
3 - 62
Version 2.0 GL-541E Operation
Compensation Values
CG. Z1 100
CG. Z2 100
CG. Z3 100
AirP Z1 50
Ref. data: 2000 [um
2
} AirP Z2 50
AirP Z3 50
G Setting Application Time and Air Pressure 523-100
FUJI
Off line
Page 523
RETURN
▼▲
Command path:
GL_541E Prod 0000 Sche 00000
GLUE
Value?
[SET] - [MANUAL] - [GLUE] - [G]
• Action of the function keys
Z1 : Press to select the Z1 syringe.
Z2 : Press to select the Z2 syringe.
Z3 : Press to select the Z3 syringe.
RETURN : Press to return to Page 523.
Chapter 3 Description of Commands
Part 3
3 - 63
Version 2.0 GL-541E Operation
SET Measuring Glue Reference Data 523-200
FUJI
Off line
Page 523
Z3Z2Z1
Command path:
GL_541E Prod 0000 Sche 00000
SET
[SET] - [MANUAL] - [GLUE] - [SET]
• Action of the function keys
SET : Press to measure the glue check reference data for the Z1 syringe.
RETURN : Press to return to Page 523.
• Explanation
Before pressing the [SET] key, position the camera over the relevant glue dot.
Chapter 3 Description of Commands
Part 3
3 - 64
Version 2.0 GL-541E Operation
Ref. data : 2000 [Um
2
]
Z1 Setting Reference Data for the Z1 Syringe 523-210
FUJI
Off line
Page 523
RETURNSET
Command path:
GL_541E Prod 0000 Sche 00000
Z1
G.ref.[%] =
[SET] - [MANUAL] - [GLUE] - [SET] [Z1]
• Action of the function keys
