Chapter 2 Explanation of Proper Data
12. MG4MASB Machine_Status_B = 0
Parameter to set special machine software modes.
Normally set to 0.
Input a decimal number after making the setting using a 16 bit binary format.
Refer to the following table for the settings. Use the calculator function in the
Windows Accessories icon group to perform this conversion.
Standard setting: 0
Mode Bit Map Hexadecimal
1000 0000 0000 0000 8000H
0100 0000 0000 0000
4000H
0010 0000 0000 0000
0001 0000 0000 0000
2000H
1000H
0000 1000 0000 0000 0800H
0000 0100 0000 0000 0400H
0000 0010 0000 0000
0200H
0000 0001 0000 0000 0100H
0000 0000 1000 0000
0080H
0000 0000 0100 0000 0040H
0000 0000 0010 0000 0020H
0000 0000 0001 0000 0010H
0000 0000 0000 1000 0008H
0000 0000 0000 0100
0004H
0000 0000 0000 0010 0002H
0000 0000 0000 0001 0001H
Using reference pin
Do not stop automatic operation
even if waiting for temperature
setting
4 - 14
Version 2.0
GL-541E Operation
Part 4
4 - 15
Version 2.0
Chapter 2 Explanation of Proper Data
13. MG4MAID Machine_ID = 0
Parameter to set special machine software modes.
Normally set to 0.
Input a decimal number after making the setting using a 16 bit binary format.
Use the calculator function in the Windows Accessories icon group to perform this
conversion.
Standard setting: 0
14. MG4PCBL PCB_Location = 0
Specify whether the reference pin is used or not used.
[0] Corner: Reference pin is not used
[1] Pin: Reference pin is used
Standard setting: 0
20. MG4LOSA Loader_ Status_A = 0
Board loader operating conditions. Not used at present.
21. MG4LOSB Loader_ Status_B = 0
Board loader operating conditions. Not used at present.
22. MG4CVT Conveyor_Type = 0
Specify the direction of board flow.
[0]: L –> R: Board flow is from left to right (standard)
[1]: R –> L: Board flow is from right to left (optional)
Standard setting: 0
23. MG4WASG Wait_Signal = 0
Specify whether the wait signal is valid or invalid.
[0]: Off: Wait signal is not valid
[1]: On:. Wait signal is valid
GL-541E Operation
Part 4
Chapter 2 Explanation of Proper Data
24. MG4BUI Busy_Invalid = 0
Specify whether or not the machine refers to board request signals from the next
stage (when unloading a board).
[0]: No: Refer to board request signals from next stage
[1]: Yes: Ignore board request signals and feed out boards when they become
available.
Standard setting: 0
25. MG4CVC Conveyor_Control = 0
Specify whether the machine is fitted with the automatic conveyor width adjustment
mechanism.
[0]: Manu: Manual conveyor adjustment
[1]: Auto: Automatic conveyor adjustment
Standard setting: 0
26. MG4CVAL Conveyor_Adj_Limit (0.05 to 1.00) [mm] = 50
Specify the tolerance for the conveyor width setting when using automatic conveyor
width adjustment
Standard setting: 50
27. MG4CVSO Conveyor_Stop_Offset (0.00 to 2.00) [mm] = 30
Specify the offset value for stopping the motor at the target position when using
automatic conveyor width adjustment.
Standard setting: 30
28. MG4CVAT Conveyor_adj_Timer (0 to 120000) [msec] = 60000
Specify the time for automatic conveyor width adjustment. If this time is exceeded, a
time-up error occurs.
Standard setting: 60000
29. MG4WMAL Width_Max_Limit (0.00 to 655.35) [mm] = 360
Specify the maximum conveyor width.
Standard setting: 360.00
30. MG4WMIL Width_Min_Limit (0.00 to 655.35) [mm] = 50
Specify the minimum conveyor width.
Standard setting: 50.00
