X : Press to change the inching speed of the X-axis.
Y : Press to change the inching speed of the Y-axis.
Q : Press to change the inching speed of the θ-axis.
Z : Press to select the Z-axis for which the inching speed is to be
changed.
RETURN : Press to return to Page 540.
• Input from numerical keypad
The rapid inching speed can be changed by inputting the desired speed with the numerical keys.
For each axis input the speed as a percent of the maximum speed during automatic operation.
Input a value in the range from 1 to 100. The speed increases as the setting is increased.
Chapter 3 Description of Commands
541-100
540
Part 3
3 - 99
Version 2.0 GL-541E Operation
(The inching speed for each axis displays here.)
SPEED Changing the Rapid Inching Speed 541
FUJI
Off line
Page 541
RETURNZQYX
Command path:
GL_541E Prod 0000 Sche 00000
INCHING SPEED
Ready
[SET] - [SERVO] - [SPEED]
• Action of the function keys To page
Z1 : Press to change the Z1-axis inching speed.
Z2 : Press to change the Z2-axis inching speed.
Z3 : Press to change the Z3-axis inching speed.
RETURN : Press to return to Page 540.
• Input from numerical keypad
The rapid inching speed can be changed by inputting the desired speed with the numerical keys.
Input a value in the range from 1 to 100. The speed increases as the setting is increased.
Chapter 3 Description of Commands
Part 3
3 - 100
Version 2.0 GL-541E Operation
(The inching speed for each axis displays here.)
Z Change the Z-Axis Inching Speed 541-400
FUJI
Off line
Page 541
RETURNZ3Z2Z1
Command path:
GL_541E Prod 0000 Sche 00000
INCHING SPEED
Ready
[SET] - [SERVO] - [SPEED] - [Z]
• Action of the function keys To page
RETURN : Press to return to Page 540.
• Explanation
The conveyor width can be inched using the [↑] [↓] keys. The conveyor width can be set using the
numerical keypad. Use the numerical keys to enter the conveyor width in units of 1/100 mm. This
value must lie within the range of board widths that the machine can handle. A value outside this
range cannot be input.
Chapter 3 Description of Commands
540
Part 3
3 - 101
Version 2.0 GL-541E Operation
CONV. WIDTH Changing and Setting Conveyor Width 542
FUJI
Off line
Page 542
RETURN
Command path:
GL_541E Prod 0000 Sche 00000
CONV. WIDTH
[SET] - [SERVO] - [CONV. WIDTH]
• Action of the function keys To page
