Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 13
SX000 No1 EMERGENCY Servo 1 emergency stop
SX001
SX002
SX003
SX004 X AXIS +OT X-axis + overtravel
SX005 X AXIS -OT X-axis - overtravel
SX006 X AXIS ZERO X-axis zero point
SX007 X AXIS READY X-axis interlock
SX008 Y AXIS +OT Y-axis + overtravel
SX009 Y AXIS -OT Y-axis - overtravel
SX00A Y AXIS ZERO Y-axis zero point
SX00B Y AXIS READY Y-axis interlock
SX00C
SX00D
SX00E Q AXIS ZERO
SX00F
LED No. Display Description
Servo Status Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 14Version 2.0
SX010 No2 EMERGENCY Servo 2 emergency stop
SX011
SX012
SX013
SX014
SX015
SX016 Z1 AXIS ZERO Z1-axis zero point
SX017
SX018
SX019
SX01A Z2 AXIS ZERO Z2-axis zero point
SX01B
SX01C
SX01D
SX01E Z3 AXIS ZERO Z3-axis zero point
SX01F
LED No. Display Description
Servo Status Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 15
LX200 LOADER PLC OK Board loader PLC OK
LX201 LOADER ALARM1 Board loader alarm 1
LX202 LOADER ALARM2 Board loader alarm 2
LX203 LOADER CMPLT Board loading operation complete
LX204 CLEAROFF CMPLT Board unloading operation complete
LX205 PCB WAIT Board waiting
LX206 NEXT WAIT Waiting for next stage
LX207 LOADER WORK Board loader operating
LX208 MAIN PCB CHK Main conveyor board check
LX209 IN PCB CHK In-conveyor board check
LX20A ID PCB OUT MCID board unloading complete
LX20B ID PCB CHK1 MCID board check
LX20C ID PCB CHK2 MCID reverse board check
LX20D W. CONV PERMIT Conveyor width change permission
LX20E LOADER ALARM3 Board loader alarm 3
LX20F
LED No. Display Description
Board Loader OP Link Input 1
GL-541E Operation
