Chapter 1 Buffer Image Display
Part 5
1.2 Buffer Image Display
The buffer image display is a display of the fiducial mark image which is held in the
buffer of the vision processing board. When a vision processing error occurs during
production, this function can be used to check the image in order to help find the cause
of the error.
The [DISPLAY] command is used to display the selected buffer image on the vision
processing monitor.
The function keys (F1~F6) shown below display when the [DISPLAY] command is
selected.
ZOOM IN: Enlarges the displayed image.
ZOOM OUT: Reduces an image that has been enlarged.
The image acquired by the mark camera cannot be reduced to a size
smaller than the size of the image when it was acquired.
SCROLL: The image can be scrolled up and down or left and right using the
scroll commands.
<<<<< Moves the image to the left.
>>>>> Moves the image to the right.
▲ Moves the image up.
▼ Moves the image down.
STEP Specifies the number of pixels the image moves each
time one of the scroll commands is pressed.
10 -> 25 -> 50 -> 100 ->10 [Pixel]
RETURN: Returns to the previous page.
ZOOM IN ZOOM OUT SCROLL RETURN
F1 F2 F4 F5 F6
F3
5 - 2
Version 2.0
GL-541E Operation
Part 5
5 - 3
Version 2.0
Chapter 1 Buffer Image Display
1.3 Reinspection Processing
Reinspection processing uses the buffer image held in the vision processing board for
carrying out vision processing.
This function is utilized to make it easier to find the cause of an error by reinspecting the
image of the fiducial mark that led to the occurrence of a vision processing error during
production.
Since the necessary information for vision processing is saved in the buffer image, the
operator can utilize this by merely selecting the buffer image.
The selected buffer image is reinspected by using the [REINSPECT] command.
The results of reinspection processing display as vision processing results at the bottom
of the first display area).
Fiducial Mark
Vision processing results
X ****** [1/1000 mm]
Y ****** [1/1000 mm]
Glue Check (single needle)
Vision processing results
AREA_1 ****** [um*um]
SQ1_X ****** [um]
SQ1_Y ****** [um]
Glue Check (single needle)
Vision processing results
AREA_1 ****** [um*um] AREA_2 ****** [um*um]
SQ1_X ****** [um] SQ2_X ****** [um]
SQ1_Y ****** [um] SQ2_Y ****** [um]
(First display area)
