Part 1 1 – 20 3.2.2 Details of the Second Display Area (Machine Error Display) Machine alarms are displayed here when something abnormal has occurred. Under normal operating conditions nothing is displayed. The meaning o…
Part 1
3.2.1 Details of the First Display Area
(a) Sequence number display
(b) Error message display
(c) Prompts to the operator
(d) Machine mode display
Operation mode: Product/Simulate/Idle
E Pass/E Stop
Glue mode (only displayed when the production program contains a glue-
check sequence): G.correct/G.ref.set
(e) Input data display
• Ready
The system is waiting for a command to be input.
• Any other display
The system is waiting for an input from the numeric keypad.
(f) Program counter display
(g) Inching axes
Displays which axes can currently be inched.
(h) Function key page number
STATUS
Seq. No. 00001 MODE : Product
Block.No. 00001 : Err Pass
Dispense mode : spot G.correct
Nozzle : L
G : 8 [x10msec]
Real_G : 96 [100/100/120]
(Error message display)
(Operator message display)
Ready 0004100001000 jogX_Y_Q Page 100
(a)
(d)
(b)
(c)
(e)
(f)
(g) (h)
1 – 19
GL-541E Operation
Version 2.0
Chapter 3 Operation Panel
Part 1
1 – 20
3.2.2 Details of the Second Display Area (Machine Error Display)
Machine alarms are displayed here when something abnormal has occurred.
Under normal operating conditions nothing is displayed.
The meaning of each of the alarms is as follows.
(a) Displays the present status of the machine.
(b) Alarms are displayed here.
Refer to Part 6, “Errors and Countermeasures”, for error details.
The status of PCB loading is also displayed.
PCB Loading: Indicates that the main conveyor is waiting for a board.
GL-541E Operation
Chapter 3 Operation Panel
Version 2.0
Part Two
Automatic Operation and Programming
