Chapter 2 Table of Command Pages
..........................................Ready.................................................................................000-000
A
ADJUST...................................Adjusting the camera. ..........................................................................522-300
AUTO ......................................Automatic operation.............................................................................100-000
AUTO ......................................During automatic operation........................................................................???
B
B MARK ..................................Inspecting a block skip mark...............................................................522-430
B MARK ..................................Inspecting a block skip mark...............................................................522-431
B MARK ..................................Inspecting a block skip mark...............................................................522-432
B MARK ..................................Inspecting a block skip mark...............................................................522-432
B MARK ..................................Inspecting a block skip mark...............................................................522-435
BUFFER IMG..........................Checking the buffer image ..................................................................522-100
C
CAMERA................................Measuring the camera Proper data....................................................531-000
CELL STAT.............................Changing the cell status.......................................................................515-210
CHANGE................................Changing the production program....................................................410-000
CHANGEOVER.....................Carrying out changeover.....................................................................170-000
CHECK IMG..........................Checking the image..............................................................................522-300
CONV WIDTH.......................Changing and setting conveyor width..............................................542-000
D
DISPLAY.................................Displaying the buffer image................................................................522-140
Command name Description
Command
page
GL-541E Operation
2. Table of Command Pages
All commands in Chapter 3 can be conveniently referred to by means of the command page.
The command page is displayed on the color display in up to three digits.
Chapter 2 Table of Command Pages
Part 3
Command name Description
Command
page
3 - 8
E
E PASS.....................................Selecting error pass or error stop........................................................512-000
F
F MARK...................................Inspecting a fiducial mark...................................................................522-420
F MARK...................................Inspecting a fiducial mark...................................................................522-421
G
G...............................................Making the Glue Data Settings...........................................................523-100
GLUE.......................................Selecting the glue commands..............................................................523-000
GLUE CHECK........................Selecting the glue check mode............................................................513-000
I
I / O .........................................Checking the inputs and outputs.......................................................521-000
INITIALIZE ............................Clearing program changeover memory............................................515-220
IN..............................................Checking the input signals..................................................................521-110
L
LINE.........................................Commands related to MCS .................................................................515-000
LMS..........................................Changing the LMS settings .................................................................515-200
LOAD PCB..............................Loading new boards.............................................................................320-000
LOAD PSTN...........................Moving the table to the loading position ..........................................330-000
LOAD PSTN...........................Measuring loader Proper data............................................................535-000
LOADER .................................Operating the loader ............................................................................300-000
M
MANUAL ...............................Setting and checking inputs and outputs..........................................520-000
MCS..........................................Changing the communication mode..................................................515-000
MEMORY................................Carrying out optional settings...................................................................C15
MEMORY................................Carrying out task selection.....................................................................C15-1
MEMORY................................Displaying the error list..............................................................................C20
Version 2.0 GL-541E Operation
