Chapter 3 Description of Commands
Part 3
3 - 17
Version 2.0 GL-541E Operation
• CYCLE STOP button
When this is pressed, “CYCLE STOP” displays in the second status area and machine operation
stops.
Note: The CYCLE STOP button has priority over the [S STOP] command. The [S STOP] command is
cleared when the CYCLE STOP button is pressed.
• When an alarm occurs
Production is interrupted and the alarms are displayed in the first or second display area. The
buzzer sounds to indicate that the RESET button should be pressed. The display returns to page
000-000 when the RESET button is pressed.
YES : Press this button to turn off the board-request sensor signal to the
previous stage and continue production. Communication with the
LMS takes place at this time and once no more boards remain on the
machine then changeover begins. After this key has been pressed
the display does not return to page 170 until changeover has been
completed.
NO : Press this key to cancel changeover if for example the
[CHANGEOVER] key is pressed by mistake.
Note: It is the operator’s decision when to press the [YES] command.
• Explanation
This command is only valid for HELPS-compatible machines where the changeover mode is
manual terminate mode or the cell status is passive cell.
Chapter 3 Description of Commands
170-000
170-000
Part 3
3 - 18
Version 2.0 GL-541E Operation
Perform changeover?
CHANGEOVER Carrying out changeover 172-000
FUJI
Off line
Page 172
NOYES
Command path:
GL_541E Prod 0000 Sche 00000
CHANGEOVER
[AUTO]- START- [CHANGEOVER]
• Action of the function keys To page
AUTO : Press to carry out automatic operation.
LOADER : Press to change to loader mode.
SEQ. NO : Press to input the desired start sequence number.
MODE : Press to select the operation mode.
RETURN : Return to page 000-000.
• START button
Pressing the START button once executes one cycle (machine action). Pressing it again carries out
the next cycle and so on.
Chapter 3 Description of Commands
100-000
300-000
140-000
150-000
000-000
Part 3
3 - 19
Version 2.0 GL-541E Operation
Press START
Step Operation STEP 200-000
FUJI
Off line
Page 200
RETURNMODESEQ. NOLOADERAUTO
Command path:
GL_541E Prod 0000 Sche 00000
STEP
[STEP]
• Action of the function keys To page
