Appendix A Chapter 1 Input Port Display A - 4 V ersion 2.0 X030 PCB LIFT UPCHK Board lifter at upper limit X031 PCB LIFT DNCHK Board lifter at lower limit X032 REF. PIN OFF Lifter pin removed confirmation X033 FLW-UP PIN…
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 3
X020 MACHINE READY Machine ready for operation
X021 AIR OK Air pressure check switch
X022
X023 SERVO OK Servo ready
X024 TABLE READY Table movement OK 1
X025 LIFTER READY Table movement OK 2
X026 (RESERVE) Short circuit
X027 (RESERVE) Short circuit
X028 FRONT DOOR OK Door safety switch
X029
X02A LOADER PLC OK Board loader PLC OK
X02B
X02C
X02D (RESERVE)
X02E
X02F
LED No. Display Description
Input 2
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 4Version 2.0
X030 PCB LIFT UPCHK Board lifter at upper limit
X031 PCB LIFT DNCHK Board lifter at lower limit
X032 REF. PIN OFF Lifter pin removed confirmation
X033 FLW-UP PIN OFF Follow-up pin removed confirmation
X034 W. CLUTCH1 ON Out conveyor width change clutch engaged
X035 W. CLUTCH1 OFF Out conveyor width change clutch disengaged
X036 W. CLUTCH2 ON In conveyor width change clutch engaged
X037 W. CLUTCH2 OFF In conveyor width change clutch disengaged
X038 W. CONV +OT Conveyor width overtravel (+) (option)
X039 W. CONV -OT Conveyor width overtravel (-) (option)
X03A
X03B REF. PIN SET OK Reference pin inserted (option)
X03C
X03D
X03E
X03F
LED No. Display Description
Input 2
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 5
X040
X041
X042
X043
X044
X045
X046
X047
X048
X049
X04A
X04B IN CONV TRAN In-conveyor board transport check (option)
X04C OUT CONV TRAN Out-conveyor board transport check (option)
X04D BKUP PIN CHK Back-up pin check (option)
X04E MAIN CNV START Main conveyor start check (option)
X04F PAPER FEED CHK Paper feed check (option)
LED No. Display Description
Input 3
GL-541E Operation
