Chapter 1 Operation
Part 2
1.2 Adjusting the Applied Glue Volume
Two types of glue application parameters are used to regulate the applied glue volume:
one type adjusts the volume applied for all dots and the other type adjusts the volume
applied for an individual dot.
1.2.1 Changing Volume for All Dots
There are two methods available for changing the applied glue volume for all of
the dots:
• Varying the application air pressure
• Varying the application time
For both methods, press the following function keys in sequence:
[SET] -> [MANUAL] -> [GLUE] -> [G]
Press the function keys to select the air pressure feedback control value (for AirP.
Z1, Z2, Z3) or the G data feedback control value (for CG.Z1, Z2, Z3 ) with the [▲]
[▼]keys. Then input those values from the numeric keypad.
• Function Key Menu
• Display in the first display area : G
CG. Z1 100
CG. Z2 100
CG. Z3 100
AirP Z1 50
AirP Z2 50
AirP Z3 50
For details refer to Part 3, Chapter 3, Description of Commands, page 523-100,
“Setting Application Time and Air Pressure”.
Note: The CG.Z1, CG.Z2, CG.Z3 values can be changed by changing the Proper data
items 113, 114, 115 G Correction Z1, Z2, Z3 and transmitting them to the
machine.
However, the air-pressure values set manually on the machine, AirP.Z1,
AirP.Z2, AirP.Z3, take precedence over Proper data. The settings do not
change when new Proper data is transmitted. The air pressure set by the
Proper data is referred to only when the machine memory is cleared by the
reset-start operation.
RETURN
▲▼
2 – 6
GL-541E Operation
Version 2.0
Part 2
2 – 7
Version 2.0
Chapter 1 Operation
1.2.2 Changing the Applied Glue Volume for Individual Dots
Particular application times (G data) can be changed by inputting values using
the [G] and [#] keys on the numeric keypad. This input can be made at any
time except during automatic operation.
Example:
To increase the G8 data by 20%, input: G 8 # 1 2 0 [CR]
This increases the glue application time from 80 ms to 96 ms.
Table of G Data Feedback Coefficients (%)
While holding down the rapid inching key [F], press the inching axis selection
key [2].
A table of G data feedback coefficients expressed in percentage form is
displayed, as shown above.
Press the [F] and [2] keys simultaneously once more and a table of application
times (expressed in milliseconds) appears. Press [F] and [2] again to return to
the original display.
Items unchanged from the original 100% are displayed in white. Items
increased to larger than 100% are displayed in purple and those decreased to
less than 100% are displayed in cyan.
G data multiplier
G01 100 % G21 100 % G41 100 % G61 100 % G81 100 %
G02 100 % G22 100 % G42 100 % G62 100 % G82 100 %
G03 100 % G23 100 % G43 100 % G63 100 % G83 100 %
G04 100 % G24 100 % G44 100 % G64 100 % G84 100 %
G05 100 % G25 100 % G45 100 % G65 100 % G85 100 %
G06 100 % G26 100 % G46 100 % G66 100 % G86 100 %
G07 100 % G27 100 % G47 100 % G67 100 % G87 100 %
G08 100 % G28 100 % G48 100 % G68 100 % G88 100 %
G09 100 % G29 100 % G49 100 % G69 100 % G89 100 %
G10 100 % G30 100 % G50 100 % G70 100 % G90 100 %
G11 100 % G31 100 % G51 100 % G71 100 % G91 100 %
G12 100 % G32 100 % G52 100 % G72 100 % G92 100 %
G13 100 % G33 100 % G53 100 % G73 100 % G93 100 %
G14 100 % G34 100 % G54 100 % G74 100 % G94 100 %
G15 100 % G35 100 % G55 100 % G75 100 % G95 100 %
G16 100 % G36 100 % G56 100 % G76 100 % G96 100 %
G17 100 % G37 100 % G57 100 % G77 100 % G97 100 %
G18 100 % G38 100 % G58 100 % G78 100 % G98 100 %
G19 100 % G39 100 % G59 100 % G79 100 % G99 100 %
G20 100 % G40 100 % G60 100 % G80 100 %
AUTO STEP LOADER PROGRAM SET
G008 00108040360000120 WAITBOARD
GL-541E Operation
Chapter 1 Operation
Part 2
Table of G Data Feedback Coefficients (ms)
Note: The feedback coefficients are cleared when the machine power is turned off or
when a new program is selected. Think of this as a way of being able to verify
revisions made to G data at F4G.
When G data is displayed in (ms) units of time, input can also be entered in
units of time.
Display in First Display Area
The screen above is displayed when the system is waiting for the START button to
be pressed to start automatic or step operation. The application time parameters
and the calculated glue application time are displayed.
STATUS
Seq.No. 00001 MODE Product
Block.No. 00001 E Stop
Dispense mode: spot G.correct
Nozzle : Z1 [4 mm]
G : 8 [x10msec]
Real_G : 96 [100/100/120]
Vertical needle stroke
Individual application time parameter
Overall application time parameter
Not used
G data multiplier
G01 10ms G21 210ms G41 410ms G61 610ms G81 810ms
G02 20ms G22 220ms G42 420ms G62 620ms G82 820ms
G03 30ms G23 230ms G43 430ms G63 630ms G83 830ms
G04 40ms G24 240ms G44 440ms G64 640ms G84 840ms
G05 50ms G25 250ms G45 450ms G65 650ms G85 850ms
G06 60ms G26 260ms G46 460ms G66 660ms G86 860ms
G07 70ms G27 270ms G47 470ms G67 670ms G87 870ms
G08 80ms G28 280ms G48 480ms G68 680ms G88 880ms
G09 90ms G29 290ms G49 490ms G69 690ms G89 890ms
G10 100ms G30 300ms G50 500ms G70 700ms G90 900ms
G11 110ms G31 310ms G51 510ms G71 710ms G91 910ms
G12 120ms G32 320ms G52 520ms G72 720ms G92 920ms
G13 130ms G33 330ms G53 530ms G73 730ms G93 930ms
G14 140ms G34 340ms G54 540ms G74 740ms G94 940ms
G15 150ms G35 350ms G55 550ms G75 750ms G95 950ms
G16 160ms G36 360ms G56 560ms G76 760ms G96 960ms
G17 170ms G37 370ms G57 570ms G77 770ms G97 970ms
G18 180ms G38 380ms G58 580ms G78 780ms G98 980ms
G19 190ms G39 390ms G59 590ms G79 790ms G99 990ms
G20 200ms G40 400ms G60 600ms G80 800ms
