ZOOM IN : Press to magnify the image displayed at the vision processing monitor ZOOMOUT : Press to reduce the image displayed at the vision processing monitor. SCROLL : Press to access the [SCROLL] command section RETURN…
TRACE : Press to access trace mode settings can be made.
REINSPECT : Press to re-execute inspection of the selected buffer image.
SEL BUF IMG : Press to select a buffer image.
DISPLAY : Press to display the selected buffer image.
RETURN : Press to return to Page 522
Chapter 3 Description of Commands
Part 3
3 - 45
Version 2.0
IMG No. INSP CAMERA ERR CODE
[1] F MARK
[2] **** **** ********
[3] **** **** ********
[4] **** **** ********
[5] **** **** ********
X 100 [1/0000 mm]
Y 30 [1/1000 mm]
BUFFER IMG Checking the Buffer Image 522-100
FUJI
Off line
Page 522
RETURNDISPLAYSEL BUF IMGREINSPECTTRACE
Command path:
GL_541E Prod 0000 Sche 00000
BUFFER IMG
Ready
[SET] - [MANUAL] - [VISION] - [BUFFER IMG]
• Action of the function keys
ZOOM IN : Press to magnify the image displayed at the vision processing monitor
ZOOMOUT : Press to reduce the image displayed at the vision processing monitor.
SCROLL : Press to access the [SCROLL] command section
RETURN : Press to return to Page 522-100
Chapter 3 Description of Commands
Part 3
3 - 46
Version 2.0 GL-541E Operation
BUFFER IMG
IMG No. INSP CAMERA ERR CODE
[1] F MARK
[2] **** **** ********
[3] **** **** ********
[4] **** **** ********
[5] **** **** ********
X 100 [1/0000 mm]
Y 30 [1/1000 mm]
DISPLAY Displaying the Buffer Image 522-140
FUJI
Off line
Page 522
RETURNSCROLLZOOM OUTZOOM IN
Command path:
GL_541E Prod 0000 Sche 00000
DISPLAY
Ready
[SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY]
• Action of the function keys
<<<<< : Press to scroll the displayed image to the left.
>>>>> : Press to scroll the displayed image to the right.
▲ : Press to scroll the displayed image upwards.
▼ : Press to scroll the displayed image downwards.
STEP : Press to display the screen at which the number of pixels for each scroll
movement can be set.
RETURN : Press to return to Page 522-140.
Chapter 3 Description of Commands
Part 3
3 - 47
Version 2.0 GL-541E Operation
BUFFER IMG
IMG No. INSP CAMERA ERR CODE
[1] F MARK
[2] **** **** ********
[3] **** **** ********
[4] **** **** ********
[5] **** **** ********
STEP 10 [Pixel]
SCROLL Scrolling Acquired Image 522-144
FUJI
Off line
RETURNSTEP
▼▲
>>>>><<<<<
Command path:
GL_541E Prod 0000 Sche 00000
SCROLL
Ready
[SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL]
• Action of the function keys
