▲ : Press to move the cursor upwards. ▼ : Press to move the cursor downwards. RETURN : Press to replace the block skip mark data specified in the production program with the values entered at the numerical keypad and ret…
▲ : Press to increase the block skip mark threshold level by increments of 1.
■ : Press together with ▲ or ▼ to increase or decrease the threshold level by
increments of 10.
▼ : Press to decrease the block skip mark threshold level by increments of 1.
RETURN : Press to return to Page 522-432.
• Explanation
If a value between 0 – 255 is entered at the numerical keypad, this value is taken as the threshold
value.
Chapter 3 Description of Commands
Part 3
3 - 58
Version 2.0 GL-541E Operation
TEST IMAGE
Sequence 1
Pattern White
Level 128
Size_x 1.23 [mm]
Size_y 1.23 [mm]
Result White
Error: 12345678
B MARK Setting the B Mark Threshold 522-432
FUJI
Off line
Page 522
RETURN
▼■▲
Command path:
GL_541E Prod 0000 Sche 00000
B MARK
Threshold level?
[SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK]
• Action of the function keys
▲ : Press to move the cursor upwards.
▼ : Press to move the cursor downwards.
RETURN : Press to replace the block skip mark data specified in the production program
with the values entered at the numerical keypad and return to Page 522-430.
• Explanation
If a value between 0 – 999 is entered at the numerical keypad, the entered value is interpreted by
the machine as the block skip mark size. When 1230 is entered, the value is set at 1.23 mm.
Chapter 3 Description of Commands
Part 3
3 - 59
Version 2.0 GL-541E Operation
TEST IMAGE
Sequence 1
Pattern White
Level 128
Size_x 1.23[mm]
Size_y 1.23[mm]
Result White
Error: 12345678
B MARK Specifying the Block Skip Mark Size 522-432
FUJI
Off line
RETURN
▼▲
Command path:
GL_541E Prod 0000 Sche 00000
B MARK
B mark size?
[SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK]
• Action of the function keys
RETURN : Press to return to Page 522-430.
• START button
When the START button is pressed, the X-axis and the Y-table move so that the specified block skip
mark is under the mark camera. An image of the mark is acquired and inspected. Data describing
the block skip mark displays on the vision processing monitor. An error occurs if there is no board
on the Y-table.
Chapter 3 Description of Commands
Part 3
3 - 60
Version 2.0 GL-541E Operation
TEST IMAGE
Sequence 1
Pattern White
Level 128
Size_x 1.23[mm]
Size_y 1.23[mm]
Result White
Error: 12345678
B MARK Executing Inspection of a B Mark 522-435
FUJI
Off line
RETURN
Command path:
GL_541E Prod 0000 Sche 00000
B MARK
Ready
[SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK]
• Action of the function keys
