Chapter 2 Trace Mode Part 5 5 - 8 V ersion 2.0 GL-541E Operation
Part 5
5 - 7
Version 2.0
Chapter 2 Trace Mode
No.14 Detail
This displays all of the graphic functions along with the detailed data for each respective
function. A trackball must be used if this setting is utilized.
No.15 Pause
Set flags when the trackball is used. This is used in combination with other functions.
No.24 Clp
This is used to verify the processing of the algorithm that is utilized with the caliper
function.
No.25 Blob
This is used to verify the processing of the algorithm that is utilized with blob analysis
processing.
No.26 Agf
This is used when a detailed check of the angle finder is carried out.
No.27 BT
This displays the results of boundary tracking on the vision processing monitor.
No.30 AcqTime
This is used when the vision processing acquisition time is output from the parallel I/O.
(Normally this is not used.)
No.31 InsTime
This is used when the vision processing time is output from the parallel I/O. (Normally
this is not used.)
GL-541E Operation
Chapter 2 Trace Mode
Part 5
5 - 8
Version 2.0
GL-541E Operation
Part 5
5 - 9
Version 2.0
Chapter 3 Adjustment Mode
3. Adjustment Mode
The adjustment mode is used to verify the status of the image when the camera focus or image
brightness has been adjusted.
The adjustment mode can be accessed by selecting [SET] -> [MANUAL] -> [VISION] ->
[ADJUST] command sequence.
The ID code must be input to enter the adjustment mode.
The function keys (F1~F6) shown below display when the [ADJUST] command is selected.
Note The display returns to the previous page if the [RETURN] key is pressed.
For additional information refer to the SMD3 Operation Manual.
3.1 Image Check
The image check function displays the image that is needed for adjusting the camera
focus and the image brightness level.
This function is utilized to check the condition of the camera focus and brightness using
the displayed image.
The function keys (F1~F6) shown below display when the [CHEK IMG] command is
selected.
Note: The display will return to the previous page if the [RETURN] key is pressed.
F1 F2 F4 F5 F6
F3
DSP REAL-IMG GET ACQ Acquired IMG RETURN
F1 F2 F4 F5 F6
F3
CHEK IMG RETURN
