AUTO : Press to carry out automatic operation. LOADER : Press to change to loader mode. SEQ. NO : Press to input the desired start sequence number. MODE : Press to select the operation mode. RETURN : Return to page 000-0…
YES : Press this button to turn off the board-request sensor signal to the
previous stage and continue production. Communication with the
LMS takes place at this time and once no more boards remain on the
machine then changeover begins. After this key has been pressed
the display does not return to page 170 until changeover has been
completed.
NO : Press this key to cancel changeover if for example the
[CHANGEOVER] key is pressed by mistake.
Note: It is the operator’s decision when to press the [YES] command.
• Explanation
This command is only valid for HELPS-compatible machines where the changeover mode is
manual terminate mode or the cell status is passive cell.
Chapter 3 Description of Commands
170-000
170-000
Part 3
3 - 18
Version 2.0 GL-541E Operation
Perform changeover?
CHANGEOVER Carrying out changeover 172-000
FUJI
Off line
Page 172
NOYES
Command path:
GL_541E Prod 0000 Sche 00000
CHANGEOVER
[AUTO]- START- [CHANGEOVER]
• Action of the function keys To page
AUTO : Press to carry out automatic operation.
LOADER : Press to change to loader mode.
SEQ. NO : Press to input the desired start sequence number.
MODE : Press to select the operation mode.
RETURN : Return to page 000-000.
• START button
Pressing the START button once executes one cycle (machine action). Pressing it again carries out
the next cycle and so on.
Chapter 3 Description of Commands
100-000
300-000
140-000
150-000
000-000
Part 3
3 - 19
Version 2.0 GL-541E Operation
Press START
Step Operation STEP 200-000
FUJI
Off line
Page 200
RETURNMODESEQ. NOLOADERAUTO
Command path:
GL_541E Prod 0000 Sche 00000
STEP
[STEP]
• Action of the function keys To page
UNLOAD PCB : Press to unload a board from the main conveyor.
LOAD PCB : Press to unload a board from the main conveyor and load a new
board.
LOAD PSTN : This function key displays when the main conveyor is not at the
loading position. Press to return the main conveyor to the load
position.
LIFTER▲ (LIFTER▼ ): This function key displays when the main conveyor is at the
loading position. Press to raise (lower) the lifter.
LOCK (UNLOCK): This function key displays when the main conveyor is at the
loading position. Press this to couple (uncouple) the in-
conveyor, main conveyor and out-conveyor.
PIN▲ (PIN▼) : This function key displays when the main conveyor is at the loading
position. Press to raise (lower) the reference pin.
RETURN : Press to return to page 000-000.
Chapter 3 Description of Commands
310-00
320-000
330-000
000-000
Part 3
3 - 20
Version 2.0 GL-541E Operation
LOADER Operating the loader 300-000
FUJI
Off line
Page 300
RETURN
PINLOCK
LOAD PSTN
LIFTER
LOAD PCB
LOAD PCB
UNLOAD PCB
UNLOAD PCB
Command path:
GL_541E Prod 0000 Sche 00000
LOADER
Board loader
[LOADER]
• Action of the function keys To page
