User Manual SIPLACE SX1/SX2/DX1/DX2 3 Technical data and assemblies From software version SC.706.xx V ersion 06/2012 EN 3.2 Performance data for SIPLACE DX1/DX2 103 3.2.3 Board conveyor dat a 3 Single conv eyor Flexible …
3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.2 Performance data for SIPLACE DX1/DX2 From software version SC.706.xx Version 06/2012 EN
102
3.2.2 Placement data
3
Component range-
a
0.4 mm x 0.2 mm to max. 200 mm x 110 mm
Component height C&P20
C&P12
TH
4 mm
6 mm
25 mm (greater height on request)
X/Y accuracy
b
C&P20 ± 41 μm (3), ± 55 μm (4) Component camera, type 23 (6 x 6)
C&P12 ± 45 μm (3), ± 60 μm (4) Component camera, type 28 (18 x 18)
C&P12 ± 41 μm (3), ± 55 μm (4) Component camera, type 30 (18 x 18)
TH ± 36 μm (3), ± 50 μm (4) Component camera, type 36 (32 x 32)
TH ± 26 μm (3), ± 35 μm (4) Component camera, type 33 (55 x 45)
TH ± 22 μm (3), ± 30 μm (4) Component camera, type 25 (16 x 16)
Angular accuracy C&P20 ± 0.5° (3), ± 0.7° (4) Component camera, type 23 (6 x 6)
C&P12 ± 0.5° (3), ± 0.7° (4) Component camera, type 28 (18 x 18)
C&P12 ± 0.5° (3), ± 0.7° (4) Component camera, type 30 (18 x 18)
TH ± 0.05° (3), ± 0.07° (4) Component camera, type 36 (32 x 32)
TH ± 0.05° (3), ± 0.07° (4) Component camera, type 33 (55 x 45)
TH ± 0.05° (3), ± 0.07° (4) Component camera, type 25 (16 x 16)
a) Please note that the component range that can be placed is also affected by the pad geometry, the customer-specific stan-
dards, the component packaging tolerances and the component tolerances.
b) The accuracy value, measured using the vendor-neutral IPC standard.
User Manual SIPLACE SX1/SX2/DX1/DX2 3 Technical data and assemblies
From software version SC.706.xx Version 06/2012 EN 3.2 Performance data for SIPLACE DX1/DX2
103
3.2.3 Board conveyor data
3
Single conveyor Flexible dual conveyor Dual conveyor in single con-
veyor mode
Standard dimensions
(length x width)
50 mm x 50 mm to
450 mm x 560 mm
a
50 mm x 50 mm to
450 mm x 262 mm
50 mm x 50 mm to
450 mm x 460 mm
Dimensions with “Long Board
b
”option
(length x width) 50 mm x 50 mm to
610 mm x 560 mm
b
50 mm x 50 mm to
610 mm x 262 mm
50 mm x 50 mm to
610 mm x 460 mm
Stationary conveyor side Right, left or outer
Automatic electrical width adjustment- Yes
PCB thickness
Standard:
"Thick board" option
0.3 mm to 4.5 mm
4.5 mm to 6.5 mm
PCB warpage See page 151
PCB weight
c
standard
“Heavy Board” option
max. 2.0 kg
max. 5.0 kg
max. 1.0 kg
max. 2.0 kg
max. 2.0 kg
max. 5.0 kg
Clearance on PCB underside
d
30 mm
PCB conveyor height
Option:
Standard:
SMEMA option:
900 mm
930 mm
950 mm
Type of interface:
Standard:
Option:
SMEMA
Siemens
Component-free PCB handling edge 3.0 mm
PCB changeover time
Single conveyor
Dual conveyor
e
< 1.5 seconds
0 seconds
a) When using board widths > 450 mm, make sure that the peripheral modules can also process these board widths.
b) Longer boards available on request
c) The board weight value refers to the weight of the board plus the weight of the components.
d) The free positioning of board supports is limited by the stop bar.
e) 0 seconds in asynchronous mode, otherwise 1.5 seconds.
Important information for machines in combination with DX2 and DX1:
When setting up a machine (S; F, HS, HF, X, SX or D series) next to a SIPLACE DX2 or SIPLACE
DX1, take note of the limited space between the two machines. In these cases, you will need a 0.5
m conveyor between the SIPLACE DX2/SIPLACE DX1 and the adjacent machines.
3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.2 Performance data for SIPLACE DX1/DX2 From software version SC.706.xx Version 06/2012 EN
104
3.2.4 Component feeding
3
Tape reel diameter 178 mm to 381 mm diameter (7“ - 15“)
Feeder locations
DX table with 60 tracks
DX table with 30 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
Max. component feeding
(Two
DX tables on the SIPLACE DX1/DX2)
When using a Waffle Pack Changer:
60 feeder modules, each with 2x8 mm X
45 feeder modules, each with 2x8 mm X
Tape reel diameter 178 mm to 381 mm diameter (7“ - 15“)
Feeder locations
DX table with 60 tracks
DX table with 30 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
