3.10.1.2 Tape reel diameter
SIPLACE SX1/SX2 3
The tape reel diameter may be up to 19" (483 mm) for all feeder modules. For a list of the maxi-
mum tape reel diameters, in accordance with the PCB conveyor height, refer to section 3.11.8.2
,
page 197
.
SIPLACE DX1/DX2 3
The tape reel diameter may be up to 15" (381 mm) for all feeder modules.
3.10.1.3 Manual removal of tantalum capacitors that were not picked up by the operator
To prevent tantalum capacitors which were not picked up from causing the tape material to burn
when it is cut, the user interface has been extended to include the option "Bei Abholfehler Bauele-
ment aus dem Gurt nehmen". This option must be enabled in SIPLACE Pro. On the placement
machine, the component that was not picked up is paced forward again until it is ready for removal
from the component tape. The track is deactivated and the operator is sent an error message to
remind him to pick up the tantalum component from the tape. If an alternative track is available,
the machine continues placing. The operator is able to stop the machine, however, and pick up
the tantalum component. If no alternative track is available and it is not possible to continue place-
ment with other components, the machine will stop. At this point, the operator can again remove
the tantalum component and acknowledge the error. Once the operator has restarted the ma-
chine, placement is continued and components are picked up from the track that is now enabled
once more.
PLEASE NOTE 3
This software function is also a good idea for expensive components. Please observe the safety
instructions for capacitors on metallic powder basis (see section 2.5.3, page 58).
User Manual SIPLACE SX1/SX2/DX1/DX2 3 Technical data and assemblies
From software version SC.706.xx Version 06/2012 EN 3.10 X feeder modules for SIPLACE SX1/SX2/DX1/DX2
161
3.10.1.4 Tape feeder module shapes for the SIPLACE X series
In general, the tape feeder modules from the X series are approx. 587 mm long and approx. 200
mm high. The width and the number of locations that it fills on the changeover table are listed in
the following table.
3
The maximum height of the interference contours above the upper edge of the tape pocket is 3
mm. As the feeder modules do not show any flaps projecting upwards and are also fixed to the
changeover tables, the risk of a head crash is reduced to a minimum.
Tape feeder
modules
Feeder module width in
millimeters
Feeder module locations
required on the changeover
table
2x8 mm X 22.6 2
8 mm X 10.8 1
12 mm X 22.6 2
Smart Feeder 12 mm X 22.6 2
Smart Feeder 16 mm X 22.6 2
16 mm X 34.4 3
24 mm X 34.4 3
32 mm X 46.2 4
44 mm X 58.0 5
56 mm X 69.8 6
72 mm X 81.6 7
88 mm X 105.2 9
3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.10 X feeder modules for SIPLACE SX1/SX2/DX1/DX2 From software version SC.706.xx Version 06/2012 EN
162
3.10.1.5 Design of the tape feeder module for the SIPLACE X series
The two following diagrams show the design of the tape feeder module for the X series with ref-
erence to the 8 mm X tape feeder module.
3
Fig. 3.10 - 1 8 mm X tape feeder module - front view
(1) Locking roller (the locking latch of the changeover table locks the feeder module in its end
position with the locking roller.)
(2) EDIF (energy and data interface)
(3) "Front" centering pin
(4) Lever for raising the pick-up window in order to thread in and remove the component tape
(5) Pickup window
(6) Exit from the tape guide channel
(7) Setting the cover foil tension
(8) Cover foil rocker
(9) Cover foil packing wheels
(10) "Back" centering pin
(11) Typeplate
