3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.2 Performance data for SIPLACE DX1/DX2 From software version SC.706.xx Version 06/2012 EN
104
3.2.4 Component feeding
3
Tape reel diameter 178 mm to 381 mm diameter (7“ - 15“)
Feeder locations
DX table with 60 tracks
DX table with 30 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
Max. component feeding
(Two
DX tables on the SIPLACE DX1/DX2)
When using a Waffle Pack Changer:
60 feeder modules, each with 2x8 mm X
45 feeder modules, each with 2x8 mm X
Tape reel diameter 178 mm to 381 mm diameter (7“ - 15“)
Feeder locations
DX table with 60 tracks
DX table with 30 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
User Manual SIPLACE SX1/SX2/DX1/DX2 3 Technical data and assemblies
From software version SC.706.xx Version 06/2012 EN 3.3 Ambient conditions and connection values
105
3.3 Ambient conditions and connection values
3.3.1 Ambient conditions for the packaging, transportation and storage
3
3.3.2 Environmental conditions for machine operation
3
3.3.3 Electrical ratings
3
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75 % (no higher than 45% on average to prevent any
possibility of condensation on the machine)
Ambient pressure > 750 mbar (corresponds to 2,500 m above mean sea level)
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 200 V~ ± 10 %; 50 Hz (North Japan)
a
3 x 220 V~ ± 10 %; 60 Hz (South Japan)
3 x 208 V~ ± 10 %; 50/60 Hz (U.S.A)
a
3 x 230 V~ ± 10 %; 50/60 Hz
3 x 380 V~ ± 10 %; 50/60 Hz
3 x 400 V~ ± 10 %; 50/60 Hz (Europe)
3 x 415 V~ ± 10 %; 50/60 Hz
3 x 25 A to max. 3 x 32 A characteristic C
3 x 25 A to max. 3 x 32 A characteristic C
3 x 25 A to max. 3 x 32 A characteristic C
3 x 25 A to max. 3 x 32 A characteristic C
3 x 16 A characteristic C
3 x 16 A characteristic C
3 x 16 A characteristic C
Mains power connection Cable 5 x 4 mm² with CEKON connector 5 x 32 A (3 x 200 V~ / 208 V~ / 220 V~/ 230 V ~)
Cable 5 x 4 mm² with CEKON connector 5 x 16 A (3 x 380 V~ / 400 V~ / 415 V~)
Energy consumption
Energy consumption
without vacuum pump
Energy consumption
with vacuum pump
b
Nominal apparent
power
SIPLACE SX1
SIPLACE SX2
SIPLACE DX1
SIPLACE DX2
1.8 kVA
2.4 kVA
1.8 kVA
2.4 kVA
3.0 kVA
3.6 kVA
3.0 kVA
3.6 kVA
Nominal active power
SIPLACE SX1
SIPLACE SX2
SIPLACE DX1
SIPLACE DX2
1.2 kW
1.6 kW
1.2 kW
1.6 kW
2.0 kW
2.4 kW
2.0 kW
2.4 kW
a) Connection at terminals 3 x 204 VAC on transformer T1
b) Vacuum pump for C&P20 head only.
3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.3 Ambient conditions and connection values From software version SC.706.xx Version 06/2012 EN
106
3.3.4 Compressed air supply and compressed air specification
3
Compressed air supply
Compressed air pressure values
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure
0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air connection
R 3/4" inner thread (pipe thread) with 1/2" hose connection
Compressed air consumption
a
Placement head configura-
tion
Compressed air
consumption-
b
without vacuum pump
Compressed air
consumption
b
with vacuum pump
c
SIPLACE SX2
SIPLACE SX1
C&P20 / C&P20
CPP / CPP
CPP / TH
TH / TH
C&P20
CPP
TH
490 Nl/min
240 Nl/min
240 Nl/min
200 Nl/min
280 Nl/min
140 Nl/min
100 Nl/min
200 Nl/min
–
–
–
100 Nl/min
–
–
SIPLACE DX2
SIPLACE DX1
C&P20 / C&P20
C&P20/C&P12
C&P12/C&P12
TH/C&P12
C&P20
C&P12
TH
490 Nl/min
520 Nl/min
550 Nl/min
375 Nl/min
280 Nl/min
275 Nl/min
100 Nl/min
200 Nl/min
–
–
–
100 Nl/min
–
–
Compressed air specification according to ISO 8573
Particle size (ISO Class 3)
5 µm
Particle density (ISO Class 3)
5 mg/m³
Maximum oil content (ISO class 1)
Particle density 0.01 mg/
m³
Pressure dewpoint (ISO class 4)
Dewpoint + 3°
a) Average consumption values
b) Under normal atmospheric conditions at 20°C and 1013 hPa.
c) Vacuum pump for C&P20 head only.
