User Manual SIPLACE SX1/SX2/DX1/DX2 2 Operational safety From software version SC.706.xx Version 06/2012 EN 2.5 Safety instructions for operating the SX1/SX2/DX1/DX2 machines 59 Please follow the instructions gi ven belo…
2 Operational safety User Manual SIPLACE SX1/SX2/DX1/DX2
2.5 Safety instructions for operating the SX1/SX2/DX1/DX2 machines From software version SC.706.xx Version 06/2012 EN
58
2.5.2 Manual insertion of board into the input conveyor
WARNING 2
Risk of injuries to hands when manually inserting a board into the input conveyor.
– When you manually insert boards into the input conveyor, make sure that you do not push the
board more than 5 cm into the machine with your hands.
– If you reach further into the machine, you will be within the gantry hazard area and there is a
risk that your hands could be injured during sudden movement of the gantry.
2
Observe the warning instructions when inserting boards into the input conveyor.
Start moving the board into the conveyor with the Move Board In function on the SC GUI.
2.5.3 Safety instructions for processing capacitors based on powdered metal
There is a risk associated with processing capacitors based on powdered metal (e.g. tantalum).
The risk is that
– an exothermic reaction, i.e. a sudden build-up of heat, may occur, if these components are
damaged. If the ambient conditions are unfavorable, and depending on the capacitance, this
buildup of heat can cause damage.
– This effect can occur when these components are cut.
Please contact your suppliers to clarify whether the components that you handle are affected.
In extremely rare cases, this risk can occur in the tape cutter of SIPLACE machines, with the re-
mote possibility of causing a smoldering fire in the waste tape.
The ambient conditions are unfavorable if:
(1) The components remain on the tape while the set tape cycle is checked (since the operator
can cycle the feeder module onward without removing components during this check).
(2) The components remain on the tape, e.g. due to a tear in the cover foil.
(3) The components remain on the tape, and the components or tape do not conform to the spec-
ification, thus increasing the pickup error rate.
User Manual SIPLACE SX1/SX2/DX1/DX2 2 Operational safety
From software version SC.706.xx Version 06/2012 EN 2.5 Safety instructions for operating the SX1/SX2/DX1/DX2 machines
59
Please follow the instructions given below to minimize the risk when placing capacitors based on
powdered metal.
(1) If the component tape is cycled onward manually, the operator must remove any components
remaining in the tape pocket.
(2) If the cover foil tears, the operator must remove any components remaining on the tape.
To prevent tantalum capacitors which were not picked up from causing the tape material to burn
when it is cut, the user interface has been extended to include the option "Stop immediately on
pickup error". This option must be enabled in SIPLACE Pro. On the placement machine, the com-
ponent that was not picked up is paced forward again until it is ready for removal from the com-
ponent tape. The track is deactivated and the operator is sent an error message to remind him to
pick up the tantalum component from the tape.
PLEASE NOTE 2
A description of how the operator can manually remove those tantalum capacitors which were
not picked up can be found in section 3.10.1.3, page 160.
2 Operational safety User Manual SIPLACE SX1/SX2/DX1/DX2
2.5 Safety instructions for operating the SX1/SX2/DX1/DX2 machines From software version SC.706.xx Version 06/2012 EN
60
2.5.4 Safety instructions for manual movement of Z axis on TwinStar
CAUTION
DANGER OF CRUSHING AT the TwinStar 2
NEVER move the Z axis down with your hand on the bumper of the return unit. The strong spring
tension of the cylinder moves the bumper back very quickly and could injure your fingers. The
same warning applies to the inside of the TwinStar, when the piston rod moves back to its original
position.
2
Fig. 2.5 - 2 Risk of crushing by return unit on TwinStar
(1) Return unit, compressed air cylinder
(2) Piston rod
(3) Bumper of the return unit
(4) Risk of crushing to fingers
