3 Technical data and assemblies
3.1 Performance data for SIPLACE SX1/SX2
3.1.1 Machine performance
3
Placement head types SIPLACE SpeedStar (C&P20)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
The placement performance is influenced by the different head combinations and head positions, plus the con-
veyor configurations. Individual options and customized applications also influence the placement performance.
On request, SIPLACE can calculate the actual performance of your product on your machine configuration.
IPC value [components/h]
According to the vendor-neutral conditions of the IPC 9850 standard published by the Association of Connect-
ing Electronics Industries.
SIPLACE benchmark value [components/h]
The SIPLACE benchmark value is measured during the machine acceptance tests. It corresponds to the condi-
tions set out in the SIPLACE scope of service and supply.
Theoretical maximum output value [components/h]
The theoretical maximum output value is calculated from the most favorable conditions for each machine type
and setting, and corresponds to the theoretical conditions normally used in the industry.
SIPLACE SX2 placement
machine
Placement area IPC value Benchmark value Theoretical value
C&P20 / C&P20 48,000 60,000 67,750
CPP / CPP
a
38,000 46,000 56,000
CPP
b
/ TH 23,100 27,000 31,000
TH / TH 10,200 11,000 13,000
SIPLACE SX1 placement
machine
Placement area IPC value Benchmark value Theoretical value
C&P20 24,000 30,000 33,875
CPP
a
19,000 23,000 28,000
TH 5,100 5,500 6,500
Placement positions- 6,000 / gantry for the Collect&Place heads
2,000 / gantry for the TwinStar
a) MultiStar CPP: low installation position
b) MultiStar CPP: high installation position
3 Technical data and assemblies User Manual SIPLACE SX1/SX2/DX1/DX2
3.1 Performance data for SIPLACE SX1/SX2 From software version SC.706.xx Version 06/2012 EN
98
3.1.2 Placement data
3
Component range-
a
0.4 mm x 0.2 mm to max. 200 mm x 110 mm
Component height C&P20
CPP
b
CPP
c
TH
4 mm
6 mm
8.5 mm to 11.5 mm
25 mm (greater height on request)
X/Y accuracy
d
C&P20 ± 41 μm (3), ± 55 μm (4) Component camera, type 23 (6 x 6)
C&P20 ± 41 μm (3), ± 55 μm (4) Component camera, type 41 (6 x 6)
CPP ± 41 μm (3), ± 55 μm (4) Component camera, type 30 (27 x 27)
CPP ± 34 μm (3), ± 45 μm (4) Component camera, type 33 (55 x 45)
TH ± 26 μm (3), ± 35 μm (4) Component camera, type 33 (55 x 45)
TH ± 22 μm (3), ± 30 μm (4) Component camera, type 25 (16 x 16)
Angular accuracy C&P20 ± 0.5° (3), ± 0.7° (4) Component camera, type 23 (6 x 6)
C&P20 ± 0.5° (3), ± 0.7° (4) Component camera, type 41 (6 x 6)
CPP
e
± 0.4° (3), ± 0.5° (4) Component camera, type 30 (27 x 27)
CPP
f
± 0.5° (3), ± 0.7° (4) Component camera, type 30 (27 x 27)
CPP ± 0.2° (3), ± 0.3° (4) Component camera, type 33 (55 x 45)
TH ± 0.05° (3), ± 0.07° (4) Component camera, type 33 (55 x 45)
TH ± 0.05° (3), ± 0.07° (4) Component camera, type 25 (16 x 16)
a) Please note that the component range that can be placed is also affected by the pad geometry, the customer-specific
standards, the component packaging tolerances and the component tolerances.
b) CPP head: in low installation position (stationary component camera not possible).
c) CPP head: in high installation position
d) The accuracy value, measured using the vendor-neutral IPC standard.
e) Component dimensions between 6 mm x 6 mm and 27 mm x 27 mm.
f) Component dimensions smaller than 6 mm x 6 mm.
