1 Introduction
This operating guide is a manual or reference work for operating and setting up the SIPLACE
®
SX1/SX2 and DX1/DX2 placement machines. This document is the original operating guide.
PLEASE NOTE: 1
– The placement machines SX1/SX2 and DX1/DX2 are in principle of identical design - any de-
viations from this will be explicitly indicated.
– For the relevant configurations and other options, refer to the individual specifications for the
SIPLACE SX1/SX2 or SIPLACE DX1/DX2 machines.
– The diagrams in this user manual show the SIPLACE SX1/SX2 as a rule. These diagrams
are also applicable in principle for the SIPLACE DX1/DX2 . However, a separate diagram of
the DX1/DX2 will be shown where necessary.
1
The header of each chapter contains the release and software version, to which this manual ap-
plies.
1
1 Introduction User Manual SIPLACE SX1/SX2/DX1/DX2
1.1 SIPLACE SX1/SX2 From software version SC.706.xx Version 06/2012 EN
16
1.1 SIPLACE SX1/SX2
1
Fig. 1.1 - 1 SIPLACE SX1/SX2 placement machine
The SIPLACE SX1 and SX2 placement machines demonstrate
– High precision,
– High configuration flexibility,
– Head and gantry modularity
– Placement performance up to the high end process range and
– A wide ranging component spectrum from 01005 components to a size of
110 mm x 10 mm.
Three placement methods are possible for processing the components:
– Collect&Place,
– Pick&Place and
– A combination of Collect&Place and Pick&Place (mixed mode).
User Manual SIPLACE SX1/SX2/DX1/DX2 1 Introduction
From software version SC.706.xx Version 06/2012 EN 1.1 SIPLACE SX1/SX2
17
The SIPLACE SX1 placement machine consists of one gantry while the SIPLACE SX2 placement
machine has two gantries. The head and gantry modularity principle developed by SIPLACE al-
lows you to change placement heads and gantries quickly and easily. For an overview of the
placement head configuration, refer to section 1.1.1
from page 17.
These can be quickly and accurately positioned by linear motors, moving independently of one
another in the X and Y directions.
The SX1/SX2 machine supports use of either the SIPLACE single conveyor or the flexible dual
conveyor.
There are two locations available for supplying components. These can be fitted with component
trolleys and configured with up to 60 tracks.
Alternatively, you can also dock a waffle pack changer (WPC5 or WPC6) at each of the two loca-
tions. If a WPC5/WPC6 is set up at one of the locations, a component trolley with 30 tracks must
be configured for the other location.
1.1.1 Overview of placement head configuration
1
Machine Placement head Standard cameras Options
SIPLACE
SX1
C&P20 Component camera, type
23
–none
CPP Component camera, type
30
– Stationary camera, type 33
TH Component camera, type
33
– Stationary camera, type 25 (only
at location 1)
SIPLACE
SX2
C&P20 / C&P20 Component camera, type
23
–none
CPP / CPP
Component camera, type
30
– Stationary camera, type 33
CPP / Twin Head
Component camera, type
30
Stationary camera, type 33
– Stationary camera, type 25 (only
at location 1)
Twin Head / Twin Head
Stationary camera, type 33 – Stationary camera, type 25 (only
at location 1)
