The following overview shows the connection options for the primary voltages of the three-phase
transformer.
4
Terminal
panel
Voltage
1U1 415 VAC
1V1 415 VAC
1W1 415 VAC
3U3 400 VAC
3V3 400 VAC
3W3 400 VAC
4U4 380 VAC
4V4 380 VAC
4W4 380 VAC
5U5 230 VAC
5V5 230 VAC
5W5 230 VAC
6U6 220 VAC
6V6 220 VAC
6W6 220 VAC
7U7 204 VAC
7V7 204 VAC
7W7 204 VAC
User Manual SIPLACE SX1/SX2/DX1/DX2 4 Setting up and commissioning
From software version SC.706.xx Version 06/2012 EN 4.2 Infrastructure at the installation location
217
4.2.3.7 Checking the inrush current limitation jumpers
The inrush current limiter of the transformer (A1) is connected in the same manner for all supply
voltages. The connectors must all be plugged into the position for input voltage 230V.
4
Fig. 4.2 - 7 Position of the board and connectors for the inrush current limitation
(1) Inrush current limiter for transformer (A1)
(2) Configuration schema
Check the connector assignment for the inrush current limiter of the transformer. The connec-
tors for all mains voltages need to be plugged into the Input Voltage 230V point.
(1)
(2)
4 Setting up and commissioning User Manual SIPLACE SX1/SX2/DX1/DX2
4.3 Setting up the machine From software version SC.706.xx Version 06/2012 EN
218
4.3 Setting up the machine
4.3.1 Warning instructions
DANGER 4
Only SIPLACE engineers or qualified people are permitted to set up and commission the machine.
Always follow the applicable accident prevention regulations.
If you still need to perform assembly work to the underside of the machine, take appropriate
measures to secure the machine first. The fork-lift must not be used as the only support.
Make sure that the gantries are positioned over the PCB conveyor area so that you do not
restrict your head movement during assembly, thus excluding the risk of injury.
Two people will be needed to adjust the height of the machine:
– One person to carry out the necessary assembly work and the other person to watch the
watch the raised machine during assembly and ensure that it does not move.
Wear special safety boots to protect your feet.
