6.16.2 SIPLACE Capacity On Demand business models
The Peak-Demand models addresses the need to cover short-term fluctuations with existing SI-
PLACE SX lines. The other model, Floating-Demand, provides customers with an alternative to
the standard package, thereby improving their financial flexibility, increasing asset productivity and
allowing full exploitation of the benefits offered with a SIPLACE SX solution.
6.16.3 Overview of SIPLACE SX machines
The SIPLACE SX must be prepared for a gantry upgrade. The SIPLACE SX machines are avail-
able in different variants.
6
The head configurations available may be limited, according to the design concerned.
Machine type Gantries Description
SIPLACE SX +
Without gan-
try
The machine is prepared for a gantry upgrade (SX1), i.e.
a trailing cable and two Gantry Control Units (GCU) are
preinstalled for one gantry.
SIPLACE SX +
Prepared
Without gan-
try
The machine is prepared for a gantry upgrade (SX1/2),
i.e. two trailing cables and three Gantry Control Units
(GCU) are preinstalled for two gantries.
SIPLACE SX1
unprepared
One gantry The machine is not prepared for a gantry upgrade (SX1),
i.e. the trailing cable and two Gantry Control Units (GCU)
are preinstalled for one gantry. An upgrade to SIPLACE
SX2 needs to be performed by the SIPLACE Service
team.
SIPLACE SX1
prepared
One gantry The machine is prepared for a gantry upgrade (SX2), i.e.
two trailing cables and three Gantry Control Units (GCU)
are preinstalled for two gantries.
SIPLACE SX2
Two gantries The machine can be torn down to give a SIPLACE SX1
Prepared. The machine is then prepared for a gantry
upgrade to SX2, i.e. two trailing cables and three Gantry
Control Units (GCU) are available.
User manual SIPLACE SX1/SX2/DX1/DX2 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.16 Capacity on Demand (SX1/SX2 only)
363
6.16.4 Head configurations
6
SIPLACE SX +
Gantry Heads
1
C&P20 A
CPP
(Low)
CPP (High)
a
Without stationary camera
TH
b
SIPLACE SX + Prepared
Gantry Heads
1
C&P20 A
CPP
(Low)
CPP (High)
a
With stationary camera
CPP (High)
a
Without stationary camera
TH
b
TH
b
2
C&P20 A
CPP
(Low)
CPP (High)
a
Without stationary camera
TH
b
CPP
(High)
TH
b
SIPLACE SX 1
Gantry Heads
1
C&P20 A
CPP
(Low)
CPP (High)
a
With stationary camera
CPP (High)
a
Without stationary camera
TH
b
TH
b
with upgrade kit from SIPLACE Service
2
C&P20 A
CPP
(Low)
CPP (High)
a
Without stationary camera
TH
b
CPP
(High)
TH
b
SIPLACE SX 1 prepared
Gantry
Heads
1
C&P20 A
CPP
(Low)
CPP (High)
a
With stationary camera
CPP (High)
a
Without stationary camera
TH
b
TH
b
2
C&P20 A
CPP
(Low)
CPP (High)
a
Without stationary camera
TH
b
CPP
(High)
TH
b
SIPLACE SX 2
Gantry Heads
1
C&P20 A
CPP
(Low)
CPP (High)
a
With stationary camera
CPP (High)
a
Without stationary camera
TH
b
TH
b
2
C&P20 A
CPP
(Low)
CPP (High)
a
Without stationary camera
TH
b
CPP
(High)
TH
b
a) CPP (high), TH and stationary camera require outer table position
b) CPP with stationary camera requires CPP (high) and outer table position
