6 Station extensions User manual SIPLACE SX1/SX2/DX1/DX2 6.3 DX changeover tables on the SIPLACE DX1/DX2 F rom software version SC.706.xx Version 06/2012 EN 340 PLEASE NOTE: Feeder mod ules can be place d on the uneven t…
User manual SIPLACE SX1/SX2/DX1/DX2 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.3 DX changeover tables on the SIPLACE DX1/DX2
339
6.3 DX changeover tables on the SIPLACE DX1/DX2
Item no. 03089820-xx DX changeover table SIPLACE DX1/DX2 with 60/2 tracks
Item no. 03089804-xx DX changeover table SIPLACE DX1/DX2 with 30/2 tracks
Item no. 03089843-xx DX changeover table docking unit for 60/2 tracks
Item no. 03089844-xx DX changeover table docking unit for 30/2 tracks
Just like the fixed DX tables, the DX changeover tables are optimized for the use of 2x8 mm SI-
PLACE tape feeder modules when using 8 mm tapes. By using 30 of these feeder modules, you
can achieve a full setup capacity of 60 8mm tracks.
The design and function of the DX changeover tables is basically identical to that of the compo-
nent changeover tables for the SIPLACE SX1/SX2 machines. See “Changeover table for SI-
PLACE SX1/SX2” on page 193.
6
Fig. 6.3 - 1 Locations for DX changeover tables, SIPLACE DX1/DX2
(1) Location 1
(2) Location 2
(T) Direction of PCB transport
(2)
(1)
6 Station extensions User manual SIPLACE SX1/SX2/DX1/DX2
6.3 DX changeover tables on the SIPLACE DX1/DX2 From software version SC.706.xx Version 06/2012 EN
340
PLEASE NOTE:
Feeder modules can be placed on the uneven track numbers. Only these tracks are fitted with an
energy and data interface on the machine, so that the full capacity of 60 8mm tracks can only be
achieved with 30 2x8mm X feeder modules. 6
CAUTION 6
The DX changeover tables may only be docked onto locations at which the DX changeover table
docking unit for the SIPLACE DX1/DX2 has been installed (fig. 5.15 - 4, page 300).
6.3.1 Safety instructions for docking the DX changeover table in or out
WARNING 6
The placement machine may only be operated if there is a DX changeover table present and
docked at each location. Fill any free locations with dummy feeder modules as described in
section 2.7.5.1, page 79.
WARNING
To prevent accidents (risk of crushing), the DX changeover table may only be docked in or out by
one person.
WARNING 6
The waste tape container must be pulled out of the DX changeover table for emptying. There is a
risk of catching your thumbs as you do so. To prevent this, observe the safety instructions in sec-
tion 5.8.2
, page 271.
CAUTION
Do not lift the DX changeover table by its handles (handles could break). 6
User manual SIPLACE SX1/SX2/DX1/DX2 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.3 DX changeover tables on the SIPLACE DX1/DX2
341
CAUTION
When docking and undocking, make sure that there are no body limbs in the travel area of the DX
changeover table. 6
6.3.2 Technical data
6
6.3.3 Docking the DX changeover table in or out
The optional DX changeover table is handled in the same way as the component trolley.
See “Docking the component trolley in or out” on page 297.
Component trolley dimensions
Component trolley with
60/2 tracks
(length x width)
Component trolley with
30/2 tracks
(length x width)
760 mm x 864 mm
760 mm x 471 mm
Height with folded-up handles
900 mm (PCB transport height:
930 mm (PCB transport height:
950 mm (PCB transport height:
934 mm
964 mm
984 mm
Weight of component trolley with 60/2 tracks
Without feeder modules
With feeder modules (fully configured)
Weight of component trolley with 30/2 tracks
Without feeder modules
With feeder modules (fully configured)
104 kg
266 kg
76 kg
157 kg
Tape reel diameter
standard
maximum
to 432 mm (17“)
483 mm (19“)
Feeder locations
DX changeover table with 60/2 tracks
DX changeover table with 30/2 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
Max. component feeding
(Two
DX changeover tables on the SIPLACE
DX1/DX2)
When using a Waffle Pack Changer:
60 feeder modules, each with 2x8 mm X
45 feeder modules, each with 2x8 mm X
Component trolley changeover time < 1 minute
