6.8 Component camera for the TwinStar, FC camera
6.8.1 Stationary P&P component camera (type 25) 16 x 16, digital (FC camera)
Item no. 00119718-xx Stationary component camera 16x16 digital, type 25
6
Fig. 6.8 - 1 Stationary P&P component camera (type 25) 16 x 16, digital (FC camera)
(1) Camera housing with integral camera and camera amplifier
(2) Glass plate - over the illumination and lens levels
6.8.2 Safety instructions
WARNING 6
When changing the placement head from TwinStar to SpeedStar, the stationary component cam-
eras of type 33, 55 x 45, digital, and type 25, 16 x 16, digital (FC camera) need to be dismantled
from the TwinStar, otherwise the SpeedStar will collide with the camera housing.
When changing the placement head from TwinStar to MultiStar, the stationary component cam-
era, type 33, 55 x 45, digital, is fitted in the bottom position.
User manual SIPLACE SX1/SX2/DX1/DX2 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.8 Component camera for the TwinStar, FC camera
353
6.8.3 Technical data
6
6
6
6
6.8.4 Position
The position of the stationary component cameras and the associated configurations are de-
scribed
in section 3.9.2
, from page 154.
Component dimensions 0.2 mm x 0.2 mm up to 16 mm x 16 mm for single component
measurement
Component range 0402 to SO, PLCC, QFP, sockets, plugs, BGA, special components,
bare dies, flip-chips, shields
Min. lead pitch 0.25 mm
Min. lead width 0.1 mm
Min. ball pitch 0.14 mm
Min. ball diameter 0.08 mm
Field of vision 19.4 mm x 19.4 mm
Illumination type Front-illumination (6 levels, programmable as required)
6 Station extensions User manual SIPLACE SX1/SX2/DX1/DX2
6.9 Component camera for the MultiStar From software version SC.706.xx Version 06/2012 EN
354
6.9 Component camera for the MultiStar
6.9.1 Component camera, stationary, P&P, type 33, 55 x 45, digital
Item no. 00519902-xx Stationary camera for the CPP head, type 33
6
Fig. 6.9 - 1 Structure for the stationary P&P component camera, type 33, 55 x 45, digital
(1) Camera housing with integral camera and camera amplifier
(2) Glass plate - over the illumination and lens levels
