CAUTION
When docking and undocking, make sure that there are no body limbs in the travel area of the DX
changeover table. 6
6.3.2 Technical data
6
6.3.3 Docking the DX changeover table in or out
The optional DX changeover table is handled in the same way as the component trolley.
See “Docking the component trolley in or out” on page 297.
Component trolley dimensions
Component trolley with
60/2 tracks
(length x width)
Component trolley with
30/2 tracks
(length x width)
760 mm x 864 mm
760 mm x 471 mm
Height with folded-up handles
900 mm (PCB transport height:
930 mm (PCB transport height:
950 mm (PCB transport height:
934 mm
964 mm
984 mm
Weight of component trolley with 60/2 tracks
Without feeder modules
With feeder modules (fully configured)
Weight of component trolley with 30/2 tracks
Without feeder modules
With feeder modules (fully configured)
104 kg
266 kg
76 kg
157 kg
Tape reel diameter
standard
maximum
to 432 mm (17“)
483 mm (19“)
Feeder locations
DX changeover table with 60/2 tracks
DX changeover table with 30/2 tracks
max. 30 feeder modules, each of 2x8 mm X
max. 15 feeder modules, each of 2x8 mm X
Max. component feeding
(Two
DX changeover tables on the SIPLACE
DX1/DX2)
When using a Waffle Pack Changer:
60 feeder modules, each with 2x8 mm X
45 feeder modules, each with 2x8 mm X
Component trolley changeover time < 1 minute
6 Station extensions User manual SIPLACE SX1/SX2/DX1/DX2
6.3 DX changeover tables on the SIPLACE DX1/DX2 From software version SC.706.xx Version 06/2012 EN
342
6.3.4 Adjusting the DX changeover table to the PCB conveyor height
The optional DX changeover table is handled in the same way as the component trolley.
See “Adjusting the component trolley to the PCB conveyor height” on page 236.
6.3.5 Setting up the feeder modules
The optional DX changeover table is handled in the same way as the component trolley.
See “Setting up the feeder modules” on page 277.
User manual SIPLACE SX1/SX2/DX1/DX2 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.4 PCB barcode scanner
343
6.4 PCB barcode scanner
Item no. 00176117-xx 2D board code reader
Item no. 00519889-xx Electrics assembly kit for 2D board code reader
Item no. 00519880-xx 1D board barcode reader
Item no. 00519890-xx Electrics assembly kit for 1D board barcode reader
Item no. 00519884-xx Mechanics assembly kit for single conveyor
Item no. 00519885-xx Mechanics assembly kit for dual conveyor
6.4.1 Description
The PCB barcode reader is used to automatically record and decode barcodes on PCBs. The
PCB barcode scanners are installed on a special frame on the input side of the placement ma-
chine on the PCB
conveyor. Depending
on the position of the barcode strips, the barcode scanner can be attached in a few simple
steps so that the strips can be read parallel to or across the PCB transport direction.
When using single conveyors, two board barcode readers can be retrofitted. These can either
scan the top or bottom of the boards.
When using dual conveyors, four board barcode readers can be retrofitted. These can scan both
the top or bottom of the boards on both conveyor lanes.
There are two variants of the barcode scanner:
– 1D board barcode readers
This barcode scanner processes barcodes. 6
– 2D board code reader
This code reader processes barcodes and matrix codes. Matrix code is primarily used when
there is
not enough space for barcode labels. 6
PLEASE NOTE:
A combination of 1D and 2D barcode reader and the 2D code reader in the same machine is not
possible. 6
