Operating Manual Reference Figure CP-45/55 Operation Process ^ <#> Column This displays the place points by i ndivid ual pa rt. You can refer t o this for determining the quantity of feed er to arrange. ^ <ARG&g…
Operating Manual Reference Figure
CP-45/55 Operation Process
That is, if there is a Feeder
arranged already, arrange new
feeder for increasing the
concurrent pickup efficiency.
If there is a feeder what you
want to apply the optimized
arrange among feeders displayed
here, move the feeder to the
right List Box by clicking the
Arrow Buttom(
)andthen
execute the Optimizer.
^ <COMP # ARG AVL LIM>
List Box
The right List Box shows
numbers of place points for
individual part, tape feeder
arranged numbers and numbers
of feeders to arrange newly.
^ <COMP> Column
All Tape Feeder Parts among the
parts being used on PCB under
Edit are displayed here.
Operating Manual Reference Figure
CP-45/55 Operation Process
^ <#> Column
This displays the place points
by individual part.
You can refer to this for determining
the quantity of feeder to arrange.
^ <ARG> Column
This displays quantity of feeder which
has been arranged on the feeder lane by
individual part. This quantity is identical
to that of feeder lane displayed on the
left List Box.
^ <AVL> List Box
This displays quantity of feeder to
arrange on the Optimizer by individual
part.
^ <LIM> List Box
This displays the sums of feeder quantity
displayed on <ARG> and <AVL> columns
by individual part. That is, this displays
the limited quantity of feeder to arrange
to individual part. The minimum value
has one.
Operating Manual Reference Figure
CP-45/55 Operation Process
^ <Limit> Button
This is used for defining the
numbers of feeder to use by
individual part. If there is one
feeder arranged already for
certain part, AVL Column
quantity will be 2 if inputting 3
in this window and pressing the
Limit button. The Optimizer
will arrange new feeders within
the max. 2 feeders. You should
set the suitable quantities of
feeders in consideration of
the numbers of place points.
For parts having a lot of place
points, you should allocate
a lot of feeders to obtain the
good work efficiency.
^ Arrow Button(
)
This can be used when
modifying the setting to feeder
to arrange newly on the
Optimizer among the feeders
arranged already.
^ <Remove Tape> Button
