Operating Manual Reference Figure CP-45/55 Operation Process @Also, if taking t he grease out of the center of a container, the bleeding phenomenon may be increased caused that the gravity is centered to the center. Thus…

Operating Manual Reference Figure

CP-45/55 Operation Process

@Also, if taking the grease out of the

center of a container, the bleeding

phenomenon may be increased

caused that the gravity is centered to

the center. Thus, reserve the grease

container with the center ascended.

@If a cover of the grease container is

damaged, moisture can be penetrated

into the container or the grease can

be oxidized by contact with an air.

Care is to be taken for preventing

from that.

Reference

# Using Method of Grease Gun

1.Couple the grease hole with a

body.

2.Disconnect a cylinder from a

handle.

3.Pull off the cylinder fill the

grease.

4.Couple the handle again.

5.Press a button by thumb and

push the cylinder to remove

an internal air.

1.2 Repair, Inspection and Maintenance of Individual Part

Warning

Failing to turn off the power switch may cause serious injury to personnel. Be

sure to turn off the power switch when maintaining individual part. Moving the

gantry by pushing the head manually may cause severe damage to the system or

injury to personnel resulted from mis-operation of the system. Do not operate the

gantry manually.
