Operating Manual Reference Figure CP-45/55 Operation Process ^ <Placement> Area This area displays quantity of part types, quantity of total mounting points, nozzle replacement times and total cycles. Since the tot…
Operating Manual Reference Figure
CP-45/55 Operation Process
# Tray Y: Time(sec) to be taken
when Tray of Multi-Tray
Feeder moves to Y direction.
#Tray Z: Time(sec) to be taken
when Tray of Multi-Tray
Feeder moves to Z direction.
If execution of Optimizer is
completed, a dialogue box will be
shown as follows. This dialogue box
displays various results so that the
optimized status can be shown at
a glance. If clicking the <Accept>
button, this dialogue box will be
closed, the Optimizer will be finished,
and this result will be reflected to
the step program of MMI. If clicking
the <Reject> button, the result will
not be reflected to the step program
of MMI and the Optimizer option
dialogue box will be open again.
If necessary, readjust the Optimizer
option and execute it again.
* Optimization Result
Operating Manual Reference Figure
CP-45/55 Operation Process
^ <Placement> Area
This area displays quantity of
part types, quantity of total
mounting points, nozzle
replacement times and total
cycles. Since the total work time
above represents the estimated
time by a simulation, it may
differ from the actual mounting
time. When calculating the
outputs, produce one PCB from
the actual machine and refer to
the time.
^ <Arrangement> Area
This area displays the
arrangement status of Tape
Feeder and ANC nozzle. Pre
represents the quantity
arranged directly by an user,
New represents the quantity
arranged newly by Optimizer,
and Total represents the quantity
arranged totally.
^ <Pickup> Area
Operating Manual Reference Figure
CP-45/55 Operation Process
This area displays distribution
for concurrent pickup of part.
Since CP-45 has the total 6
heads, there are 6 types from
individual pickup to concurrent
pickup of 6 heads. Numbers
and ratio of the mounting points
worked by individual concurrent
pickup type will be shown in
this area.
#I : In case that only one head
picks the part(Individual
pickup)
#2S : In case that 2 heads pick
the part concurrently.
#3S : In case that 3 heads pick
the part concurrently.
#6S : In case that 6 heads pick
the part concurrently.
^ <Cycle> Area
This area displays part
assignment, feeder assignment,
and nozzle assignment status of
the final step program. 3 radio
buttons shown as follows enable
