CP-45/55 Operation Process
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1. PCB EDIT Overview & Edit
Procedure
This is to place parts of chip type
and deformed parts with Array
board and consists of 4 steps of
Board, Part, Feeder and Step.
1.1)
PCB Edit Overview
V
Board
Size: 300 X 300, 1EA
Array: 3 X 3, 9EA (General Type)
Fiducial Mark: 2 Points,
Circle Type
V
Part (Standard Part)
New Create:
Chip,Melf,Tr,A/C,Tantal,BGA
Auto Teach: SOP, QFP
V
Feeder
Tape Feeder : 1 Slot by each part
Stick Feeder : Vibration
Tray Feeder : Single
V
Step
V
9 Points Teaching (1st Board)
Part / Feeder / Nozzle /
Head / Cycle. Finish
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1.2)
PCB Edit Procedure
1.2-1)
File
V
New -> Create
1.2-2)
PCB Edit (1)
Board / Part / Feeder / Step
/ Optimizer
V
Board
^Customer Name / Board Name
^Coordinate (Coordinate Setting)
^Board Size / Conveyor Width
^Handling / PCB In
^Place Origin
^Array
^Fiducial Mark Part
To (Work Part Register)
V
Part (Work Part Register)
^Copy from existing PCB File
Register to Part List
^New Part (New Part Register)
Part Name & Group
AlignData&CommonData
To Feeder (Feeder Setting)
V
Feeder (Feeder Register)
^Stick Feeder Place
^Tray Feeder Place
^Tape Feeder Place Step
To (Place Program Setting)
