Operating Manual Reference Figure
CP-45/55 Operation Process
1.2.3.9 Operation of Conveyor
Cylinder
*Check Points*
@Check individual cylinder for proper
operation.
@Check for the operation sensor of
individual cylinder.
*Actions to be taken*
@You may use Manual I/O Test, Self
Diagnostic on MMI monitor for
easy check.
@If abnormal conditions occur,
contact our C/S center for A/S.
Caution
Avoid inserting parts of a body into the system during
I/O Test. Failing to observe this may cause serous
injury to personnel.
Operating Manual Reference Figure
CP-45/55 Operation Process
1.2.4 Electric Device
*Check Points*
@Check every device for worn
conditions.
@Check that an error occurs to the
system during Switch operations.
@Check that the relevant input IO of
MMI IO window operates properly.
(Emergency Switch , Door Switch)
@Check whether the power is off or
not during the current breaker
operations.
*Actions to be taken*
@If the part is worn excessively or
fails to operate, contact our
designated C/S company for A/S.
Caution
Be sure to turn off and lock the power when
checking for the wear conditions.
