Operating Manual MODEL Reference Figure CP-45/55 Operation Process v Chip Mo unter VME(Controlle r) v Operation Program (MMI : Man Machine Interface) v Operator 1 2 3 4 5 6 * MMI (Operation Concept) 1. Production 2. Do w…
PCB EDIT
* MMI Operation Concept
* General Board Programming
* Safety Training
* PCB Edit Practice
CP-45/55 Operation Process
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
v
Chip Mo unter
VME(Controller)
v
Operation Program
(MMI :
Man Machine Interface)
v
Operator
1
2
3
4
5
6
* MMI (Operation Concept)
1. Production
2. Down Load Program
3. Step
: Place Position Information Input
4. Feeder
: Feed Position Information Input
5. Part
: PCB Part Information Input
6. Board
: PCB Information Input
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
Stick
Coordinate
Size
PCB
Origin
Stopper
Conveyor
Tray
Tape
* Key Program Contents
v
Board : Board Information
Input
Coordinates / Size
Origin Point
/ Fiducial Mark….
v
Part:PartInformationInput
Part Name
Align Data
Nozzle / Feeder…
v
Feeder :
Feed Position
Information Input
Feeder Type
-[Tape/Stick]
Feed Position….
v
Step : Place Position
Information Input
Place Position
Step / Cycle …
