Operating Manual Reference Figure CP-45/55 Operation Process This determines the method for optimizing the Array PCB in the Optimizer. If selecting <By PCB>, the step program will be created on the optimizer making…
Operating Manual Reference Figure
CP-45/55 Operation Process
If all heads are prohibited, an
error message will be shown
immediately on the Optimizer.
^ <Array Option> Box Area
This is to use for setting the
display method of MMI step
program and the optimized
option when editing the Array
PCB. The Array PCB can
display only one Unit PCB on
the step program, repeated work
to be carried out by individual
PCB, or the optimized step
program to be shown for the
entire PCB. This function can
be selected on the step edit
screen of MMI. Where, if
selecting the former, do not
check the <Extend> in the
<Array Option> box, and if
selecting the latter, check it.
<By PCB / By Point >
This combo box will be active
only when <Extend> was
selected.
Operating Manual Reference Figure
CP-45/55 Operation Process
This determines the method for
optimizing the Array PCB in the
Optimizer. If selecting <By PCB>,
the step program will be created
on the optimizer making sure that
the optimized program for only
one PCB to be created and then
several unit PCBs are to be
edited in sequence. On the other
hand, if selecting <By Point>, by
considering the entire PCB as
one, the optimized program for
all mounting points will be
created. For example, for the
Array PCB which consists of unit
PCB of 4 sheets, it is
programmed in order that for
<By PCB> option, work of one
PCB to be completed and then
work of the next PCB to be
completed, and for <By Point>
option, the mounting work is to
be carried out with mixing of No.
1, 2, 3 and 4 PCBs. Generally
the latter can increase the entire
work efficiency.
Operating Manual Reference Figure
CP-45/55 Operation Process
However,iftherearealotof
defectives of unit PCB, the
latter can decrease the work
efficiency when comparing with
the former.
^ <Optimization Options> Area
This area is to set the self-
option of the optimized
algorithm executed on Optimizer.
Since basic selection is done,
you may use this as it is. For
the order of mounting the part
on PCB, mount the part in order
of from the higher to the lower.
Failing to observe this rule may
cause that the nozzle can be
crashed against the part which
has been mounted already.
<Component Height> option
determines how strictly this rule
applies. Applying this rule too
strictly may cause a program
of too low efficiency.
