Operating Manual MODEL Reference Figure CP-45/55 Operation Process 1 2 3 *F l y i n gC a m e r a 1. Camera 2. Mirror 3. Head

Operating Manual

MODEL

Reference Figure

CP-45/55 Operation Process

*HEAD

1. Beam 1-Teaching(1-10)

2. R Motor(Rotation)

3. Mirror

4. Move Camera

5. Flying Camera(6ea)

22mm

6. Z Motor(UP,down)

7. Z Spindle(6ea)

Operating Manual

MODEL

Reference Figure

CP-45/55 Operation Process

*FlyingCamera

1. Camera

2. Mirror

3. Head

Operating Manual

MODEL

Reference Figure

CP-45/55 Operation Process

Tape Feeder

Stick Feeder

Tray Feeder

* FEEDER

1.Tape Feeder

Mechanical Type

For both Paper / Emboss

1005,0603 Exclusive Feeder

8 ~ 56mm General Feeder

ChipR/C,Tantal,TR,Melf

SOIC,Connector….

2.Stick Feeder

Vibration / Belt

Only for Stick

Multi / Single

SOIC,PLCC,Connector,PTR…

3.Tray Feeder

Fixed/Shuttle

Only for Tray

Single / Multi

TSOP,QFP,BGA…
