P P C C B B E E D D I I T T 2 2 * Board (Origin, Array,Fiducial Mark,Initial Theta) * Part (Library Concept,New Part Preparing Method… ) * Feeder (Tape Feeder Types,Concurrent Pickup Condition… ) * Step (Coordinates Modi…
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
*
OPTION
^ Production Range
1) CB Production Plan Quantity
2) Production Range Option
^
Operation Option
1) ANC replacement can be
executed during PCB transfer.
2) Stop when Dumping.
3) Prior feeding of Feeder of
1Cycle.
4) Camera position checked as an
interval of Data inputted when
using Fix Camera.
5) Camera Option to display on
Vision Monitor in production.
6) PCB Transfer Speed Option
P
P
C
C
B
B
E
E
D
D
I
I
T
T
2
2
* Board
(Origin, Array,Fiducial Mark,Initial Theta)
* Part
(Library Concept,New Part Preparing Method…)
* Feeder
(Tape Feeder Types,Concurrent Pickup Condition…)
* Step
(Coordinates Modification Method,Step Edit…)
CP-45/55 Operation Process
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1. PCB EDIT Overview & Edit
Procedure
This is to place parts of chip type
and deformed parts with Array
board and consists of 4 steps of
Board, Part, Feeder and Step.
1.1)
PCB Edit Overview
V
Board
Size: 300 X 300, 1EA
Array: 3 X 3, 9EA (General Type)
Fiducial Mark: 2 Points,
Circle Type
V
Part (Standard Part)
New Create:
Chip,Melf,Tr,A/C,Tantal,BGA
Auto Teach: SOP, QFP
V
Feeder
Tape Feeder : 1 Slot by each part
Stick Feeder : Vibration
Tray Feeder : Single
V
Step
V
9 Points Teaching (1st Board)
Part / Feeder / Nozzle /
Head / Cycle. Finish
