Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1
4
2
5
3
6
* Name of Key Components
1.
Head(6ea)
Pick & Placer
2.
Camera
Flying & Fixed
3.
ANC
Auto Nozzle Changer(37Hole)
4.
Feeder
Part Feeder(8~56)
5.
Conveyor
Board Conveyor(50~400)
6.
MMI
(Operation Program)
Man Machine Interface
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
4
2
1
3
5
6
7
*HEAD
1. Beam 1-Teaching(1-10)
2. R Motor(Rotation)
3. Mirror
4. Move Camera
5. Flying Camera(6ea)
22mm
6. Z Motor(UP,down)
7. Z Spindle(6ea)
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1
2
3
*FlyingCamera
1. Camera
2. Mirror
3. Head
