Operating Manual Reference Figure
CP-45/55 Operation Process
Click the <Remove Button>
when arraying newly all of
Tape Feeder by ignoring all of
Tape Feeders arrayed which
have been arrayed already.
Since this button remains on the
bottom of Optimizer setup
screen, you can select it even
though Tape Feeder setup tap is
not shown.
* Setup Menu/Nozzle
This screen is to set the optimized
arrangement of Nozzle. All nozzles
registered to the system are shown
in <Arranged>, <Available> and
<Prohibited> list boxes, and the
sums of numbers of individual
nozzle shown in every List Box are
identical to numbers of all heads.
(6 for CP-45)
You can set the nozzle numbers as
much as what you want to arrange
it on the Optimizer by adjusting the
numbers in <Available> List Box.
Operating Manual Reference Figure
CP-45/55 Operation Process
^<Nozzle> Area/<Arranged>
List Box
An user can directly arrange
the nozzle on ANC pocket in
ANC Setup Dialogue. The
nozzles arranged already as
like this will be shown in
<Arranged> List Box as much
as the numbers arranged.
The nozzle listed in the box
can be used for the work,
however, can not be arranged
in the pocket optionally by
Optimizer. If you want to
re-arrange the nozzle arranged
already, select the desirable
nozzle, press the arrow button
(
) and then move it to the
<Available> List Box.
If an user want to directly
arrange again the nozzle,
pop-up the ANC Setup Dialogue
and assign the pocket.
Operating Manual Reference Figure
CP-45/55 Operation Process
^ <Nozzle> Area/<Available>
List Box
This is to assign the nozzle to
arrange in pocket on Optimizer.
If executing the Optimizer in
case as shown in Fig. A.3, one
TN14 nozzle and two TN22
nozzles will be arranged in the
empty nozzle pocket. Numbers of
nozzle to arrange by use of the
Optimizer can be increased or
decreased freely by clicking
the arrow buttons
and
between <Available> List Box
and the <Prohibited> List Box.
^ <Nozzle> Area/<Prohibited>
List Box
This List Box functions as the
a buffer for holding the
unnecessary nozzles. You may
put all of the unnecessary
nozzles in the <Prohibited> List
Box.
