Operating Manual Reference Figure CP-45/55 Operation Process #Nozzle: Nozzle assignment status shows which nozzle uses for certain nozzle. A name of n o z z l et ob eu s e do n individual head will be displayed.
Operating Manual Reference Figure
CP-45/55 Operation Process
to show individual assignment
status optionally. Number shown
in the right column means the
repeat numbers of these cycles.
#Component: The part
assignment status is displayed
as c
x
for part to be worked by
individual head as c
x
,where
x
is
a number counted respectively
for part types.(in this case, not
displayed as a part name)
# Feeder: Feeder assignment
status is displayed with the
feeder lane to be picked-up by
individual head, the front feeder
base represents as F
x
and the
rear feeder base represents as
R
x
.Where
x
is a number of
feeder lane. Also, stick feeder
and tray feeder represent as S
x
and T
x
respectively. Where,
x
differs from a name of feeder
unit as a classification based
upon the pickup position.
Operating Manual Reference Figure
CP-45/55 Operation Process
#Nozzle: Nozzle assignment
status shows which nozzle uses
for certain nozzle. A name of
nozzletobeusedon
individual head will be displayed.
• Utility
• Diagnosis
Utility/Diagnosis
CP-45/55 Operation Process
