Operating Manual Reference Figure

CP-45/55 Operation Process

# Lubricating Method

Check for the lubrication interval.

@Do not apply the grease mixed with

other greases.

@Apply grease through Grease Nipple

with the Grease Gun.

(Recommended Grease Applying

Quantity : 5g/1 time for one block)

@Grease can not be lubricated to

Ball rolling part when LM Block stops.

Thus, lubricate it by moving the

Gantry slowly. (Y-axis)

@Check the lubricated condition of

grease by the low-speed operation

with Teaching Box.

@Warm up the system for 1 minute

for ensuring the suitable distribution

of grease.

# Applying Method

Apply the grease thinly to the entire

surface of a rail or a slot of screw

with a brush after removing dust or

foreign materials with dust-proof cloth.

Then, remove the surplus grease on

both ends of rail or screw by moving

slowly the relevant axis 2~3 times.

Operating Manual Reference Figure

CP-45/55 Operation Process

@Also, if taking the grease out of the

center of a container, the bleeding

phenomenon may be increased

caused that the gravity is centered to

the center. Thus, reserve the grease

container with the center ascended.

@If a cover of the grease container is

damaged, moisture can be penetrated

into the container or the grease can

be oxidized by contact with an air.

Care is to be taken for preventing

from that.

Reference

# Using Method of Grease Gun

1.Couple the grease hole with a

body.

2.Disconnect a cylinder from a

handle.

3.Pull off the cylinder fill the

grease.

4.Couple the handle again.

5.Press a button by thumb and

push the cylinder to remove

an internal air.
