Operating Manual MODEL Reference Figure CP-45/55 Operation Process * General Board Program (Only for Chip) 1. PCB Edit Overview & Edit Procedure This is to place parts of chip type with general board and consists of …
1. Warning
Do not run the machine when window is open or interlock is broken.
2. Danger
Removing the cover on which this label is attached may cause an electric shock.
When removing the cover for maintenance, be sure to remove it after turning off
the power and waiting for a moment.
3. Warning
Severe care is to be taken for an electric shock because high voltage flows inside of
a cover or in a part of connectors. Be sure to place the lock unit after turning off
the main power switch when maintaining it.
4. Warning
Severe care is to be taken for an electric shock because residual current remains
in electric parts in the cover even though power switch is OFF.
5. Warning
Be sure to disconnect a power and an air prior to maintenance.
6. Warning
Do not put yours hands in machine during its operation. Since a place on which
this label is attached is equipped with moving parts, disassembling the machine,
opening its cover or putting parts of a body through the machine during its
operation may cause severe damage to the machine or serious injury to personnel.
Stop the machine prior to service. Be sure to stop the machine in advance for
maintaining it or taking corrective actions.
CP-45/55 Operation Process
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
*
General Board
Program (Only for Chip)
1. PCB Edit Overview & Edit
Procedure
This is to place parts of chip type
with general board and consists
of 4 steps of Board, Part, Feeder
and Step.
1.1) PCB Edit Overview
v
Board
Size: 200 X 200, 1EA
v
Part (Standard Part)
Use with Library: Chip R 2 kinds
registered
v
Feeder
Tape Feeder
: 1 Slot by each part
v
Step
12 Points Teaching
Consisted of 2 Cycles by
Part setting, Feeder option
and NZ,HD Finish….
Operating Manual
MODEL
Reference Figure
CP-45/55 Operation Process
1.2) PCB Edit Procedure
1.2-1)File
v
New Create
(New Board Program Create)
1.2-2) PCB Edit (1)
Board / Part / Feeder / Step
/ Optimizer
v
Board
^ Customer Name / Board Name
^ Coordinate (Coordinates Setting)
^ Board Size / Conveyor Width
^ Handling / PCB In Part
To (Work Part Register)
v
Part (Work Part Register)
^ Use with Library
Register to Part List
Align Data & Common Data Check
To Feeder (Feeder Setting)
v
Feeder (Feeder Register)
^ 1 Slot by each part
