3 Technical data for the machine User Manual SIPLACE D1/D2 3.3 Ratings From software version SR.605.xx 07/2008 EN Edition 100 3.3 Ratings 3.3.1 Electrical ratings 3 30 tape feeder modules 2 x 8 mm S (60 tr acks) 30 tape …
User Manual SIPLACE D1/D2 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.2 Performance data for the SIPLACE D2 machine
99
3.2 Performance data for the SIPLACE D2 machine
3
Types of placement
head
12-segment Collect&Place head (C&P12)
6-segment Collect&Place head (C&P6)
PLEASE NOTE IPC value [comp./h]
According to the vendor-neutral conditions of the IPC 9850 standard
published by the Association of Connecting Electronics Industries.
SIPLACE Benchmark value [comp./h]
The SIPLACE benchmark value is measured during the machine accep-
tance tests. It corresponds to the conditions set out in the SIPLACE
scope of service and supply.
Theoretical maximum output value [comp./h]
The theoretical maximum output value is calculated from the most
favorable conditions for each machine type and setting, and corre-
sponds to the theoretical conditions normally used in the industry.
Number of gantries
2
IPC value
Benchmark val-
ue Theoretical value
Placement head
configuration and
placement head rate
[comp./h]
2 x C&P12
C&P12/C&P6
C&P6/C&P6
27,200
20,900
16,500
31,000
23,000
19,500
40,500
32,000
23,000
Range of compo-
nents
0.4 x 0.2 mm² (01005)
a
0.6 x 0.3 mm² (0201)
b
to 27 x 27 mm²
Component height C&P12: 6 mm
C&P6: 8.5 mm
Placement accuracy C&P12: CO camera type 28 (18x18): ± 50 μm (3σ), ± 67 μm (4σ)
CO camera type 29 (27x27): ± 50 μm (3σ), ± 67 μm (4σ)
CO camera type 38 (16x16): ± 50 μm (3σ), ± 67 μm (4σ)
C&P6: CO camera type 29 (27x27): ± 52.5 μm (3σ), ± 70 μm (4σ)
Angular accuracy C&P12: CO camera type 28 (18x18): ± 0.53° (3σ), ± 0.71° (4σ)
CO camera type 29 (27x27): ± 0.53° (3σ), ± 0.71° (4σ)
CO camera type 38 (16x16): ± 0.53° (3σ), ± 0.71° (4σ)
C&P6: CO camera type 29 (27x27): ± 0.225° (3σ), ± 0.3° (4σ)
Component feeding 2 component trolleys with tape reel container and integral waste con-
tainer
(15 x 30 mm wide locations per component trolley )
Feeder module
types
Tapes, bulk cases, stick magazines, application-specific OEM feeder
modules, surftape feeder modules (8, 12, 16 mm)
Feeding capacity 30 tape feeder modules 3 x 8 mm S (90 tracks)
3 Technical data for the machine User Manual SIPLACE D1/D2
3.3 Ratings From software version SR.605.xx 07/2008 EN Edition
100
3.3 Ratings
3.3.1 Electrical ratings
3
30 tape feeder modules 2 x 8 mm S (60 tracks)
30 tape feeder modules 12/16 mm S (30 tracks)
20 tape feeder modules 24/32 mm S (20 tracks)
14 tape feeder modules 44 mm S (14 tracks)
12 tape feeder modules 56 mm S (12 tracks)
PCB format
(LxW)
Single conveyor
50 x 50 mm² to 460 x 460 mm²
50 x 80 mm² to 610 x 460 mm² (Long board option)
Width up to 508 mm for Wide board configuration
Dual conveyor
50 x 50 mm² to 460 x 216 mm²
50 x 80 mm² to 610 x 216 mm² (Long board option)
Width up to 242 mm for Wide board configuration
Dual conveyor in Single conveyor mode
50 x 50 mm² to 460 x 380 mm²
50 x 80 mm² to 610 x 380 mm² (Long board option)
Width up to 430 mm for Wide board configuration
PCB thickness 0.3 to 4.5 mm (thicker PCBs available on request)
a) With 01005 package
b) With 0201 package
Supply voltage 3 x 200 VAC ± 5%; 50/60 Hz (Japanese version)
3 x 208 VAC ± 5%; 50/60 Hz (U.S.A. version)
3 x 230 VAC ± 5 %; 50/60 Hz
3 x 380 VAC ± 5 %; 50/60 Hz
3 x 400 VAC ± 5 %; 50/60 Hz (European version)
3 x 415 VAC ± 5 %; 50/60 Hz
Fuse 3 x 16 A (3 x 200 VAC / 3 x 208 VAC / 3 x 230 VAC
/ 3 x 380 VAC / 3 x 400 VAC / 3 x 415 VAC)
Nominal apparent power 2 - 3 kVA
Rated current consumption 3 - 5 A / 3 x 400 VAC
User Manual SIPLACE D1/D2 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.3 Ratings
101
3.3.2 Pneumatic ratings and compressed air specification
3.3.2.1 Pneumatic ratings
3
3.3.2.2 Compressed air specification
3
3.3.3 Ambient conditions
3
3
3.3.4 Ambient conditions for the packaging, transportation and storage
3
Compressed air pressure
p
min
p
max
0.55 MPa = 5.5 bar
1.0 MPa = 10 bar
Compressed air connection R 3/4" internal thread (pipe thread) with 1/2" hose
connector
Compressed air consumption
a
with 2 tape
cutters
SIPLACE D1 with C&P/P&P head
SIPLACE D2 with 2 x C&P head
a) Under normal atmospheric conditions at 20°C and 1013 hPa
345 Nl/min
205 Nl/min with the vacuum pump
b
485 Nl/min
205 Nl/min with the vacuum pump
b
b) See Section 6.17
, page 312
Operating pressure 0.52 MPa ± 0.01 MPa (5.2 bar ± 0.1 bar)
Particle size 0.1 μm
Particle density 0.1 mg/m³
Maximum oil content (class 1) Particle density 0.01 mg/m³
Pressure dewpoint (class 4) Dewpoint + 3°C
Temperature range Between 15°C and 35°C
Relative atmospheric humidity Between 30% and 90% at 20°C
Ambient pressure > 750 mbar (corresponds to 2,500 m above mean sea level)
Temperature range Between -25°C and 55°C
Relative atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
