User Manual SIPLACE D1/D2 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.9 Vision system
143
3.9.4.4 Ink spot criteria
3
Methods - Synthetic fiducial recognition method
- Mean grayscale value
- Histogram method
- Template matching
Shapes and sizes of fiducials/
structures for
Synthetic fiducials
Other methods
For dimensions of synthetic fiducials, see Section 3.9.4.3
Fidu-
cial criteria
Min. 0.3 mm
Max. 5 mm
Masking material Good coverage
Recognition time Depends on the method: 20 ms - 0.2s
3 Technical data for the machine User Manual SIPLACE D1/D2
3.10 Feeder modules From software version SR.605.xx 07/2008 EN Edition
144
3.10 Feeder modules
The following feeder modules are currently available to provide the machine with the various com-
ponent types:
3.10.1 Feeder modules for SIPLACE D1
3.10.1.1 Tape feeder modules
– 8 mm SII feeder module
– 3 x 8 mm S feeder module
– 3 x 8 mm S feeder module for 01005 components in paper tapes
– 3 x 8 mm S feeder module for 0201/0402 components in paper tapes
– 3 x 8 mm SL
a
feeder module from 0201 components in paper or blister tapes
– S feeder module for 12/16 mm, 24/32 mm, 44 mm, 56 mm, 72 mm and 88 mm
– S DP feeder module for deep pockets, 24/32 mm, 44 mm and 56 mm
3.10.1.2 Other feeder modules
– Linear vibratory feeder, type 3
– Bulk case feeder module
– Surf tape feeder module for 8 mm, 12 mm and 16 mm
– Waffle-pack tray holder
3.10.2 Feeder modules for SIPLACE D2
3.10.2.1 Tape feeder modules
– 8 mm SII feeder module
– 3 x 8 mm S feeder module
– 3 x 8 mm S feeder module for 01005 components in paper tapes
– 3 x 8 mm S feeder module for 0201/0402 components in paper tapes
– 3 x 8 mm SL
a
feeder module from 0201 components in paper or blister tapes
– S feeder module for 12/16 mm, 24/32 mm, 44 mm and 56 mm
a SL = shutterless, that is without any component cover
User Manual SIPLACE D1/D2 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.10 Feeder modules
145
3.10.2.2 Other feeder modules
– Bulk case feeder module
– Surf tape feeder module for 8 mm, 12 mm and 16 mm
3
3.10.3 Description
These feeder modules can be used to process all components with the most common package
forms, such as bulk cases, stick magazines and taped components.
The most important feature of the modular component feeding system is its great flexibility. For
example, the conveyor increment can be set on the feeder module. Paper and blister tapes can
be processed with the tape feeder modules. A small range of feeder module types is sufficient to
place a large range of component types.
The position detection system on the 8 mm feeder modules can precisely determine the compo-
nent pick-up position. The position detection is carried out automatically whenever the feeder
module or component trolley is changed.
The feeder modules can be quickly and easily changed or replaced, even by unskilled personnel.
PLEASE NOTE
Detailed information on the feeder modules can be found in the manuals and job guides for
feeder modules.
3.10.4 Tape material
The possible tape widths range from 8 mm to 88 mm. The tape material is blister or paper. Com-
ponent tapes with a permanently adhesive cover foil (PSA foil) can also be processed. This will
require the "PSA Kit" option.
3.10.5 Tape reel diameter
The tape reel diameter may be up to 19" (483 mm) for all feeder modules. A list of the maximum
tape reel diameters in relation to the PCB conveyor height can be found in Section 3.11.4.1
, page
175
.
PSA Kit Item no.
8 mm SII PSA Kit 00141216-xx
12 mm / 16 mm S PSA Kit 00141218-xx
