PLEASE NOTE 6
Not the following points when you insert the magazine:
→ The centering pins slide into the centering hole (item 3 in Fig. 6.1 - 5
, page 267) and into the
slot (item 4 in Fig. 6.1 - 5
, page 267).
→ The parallel pin of the slide mechanism (item 5 in Fig. 6.1 - 5
, page 267) slides into the hole
(item 6 in Fig. 6.1 - 5, page 267) in the magazine.
→ First place the side of the magazine with the numbered nozzles 1, 2, 3 and 4 on the base.
The retaining clamp (item 2 in Fig. 6.1 - 5
, page 267) must slide into the slot in the magazine.
→ Push the spring hook away from the magazine (item A in Fig. 6.1 - 5
, page 267).
→ Press the magazine so that it lies flat on the base, then release the spring hook (item 1 in Fig.
6.1 - 5
, page 267). The spring hook must latch into place.
6.1.1.8 Position detection
Every magazine of the nozzle changer has a positioning fiducial for position detection.
6
Fig. 6.1 - 6 Nozzle changer - Position detection
(1) Positioning fiducial
(2) Position of the nozzles in the magazine relative to the positioning fiducial
User Manual SIPLACE D1/D2 6 Station extensions
From software version SR.605.xx 07/2008 EN Edition 6.1 Nozzle changer
269
6.1.2 Nozzle changer for the 6-segment Collect&Place head
Item no. 00119866-xx Nozzle changer, 6-segment Collect&Place head, D1/D2
6.1.2.1 Description
This nozzle changer can hold up to 4 magazines, each with 6 nozzle holders. There are two types
of magazine available: magazines for type 8xx nozzles and magazines for type 9xx nozzles. The
magazines are seated on a common support. They are centered using two parallel pins and fixed
in place with clips.
Standard configuration: 3 magazines for type 9xx nozzles
1 magazine for type 8xx nozzles
6
Fig. 6.1 - 7 Nozzle changer for the 6-segment Collect&Place head
(1) Magazine for type 9xx nozzles
(2) Magazine for type 8xx nozzles
WARNING 6
→ Only install the associated nozzle changer for each placement head. There is a risk of head
crashes with mixed configurations.
6 Station extensions User Manual SIPLACE D1/D2
6.1 Nozzle changer From software version SR.605.xx 07/2008 EN Edition
270
6.1.2.2 Technical data
6
6.1.2.3 Position of the nozzle changers for the C&P6 head
D1 placement machine 6
One nozzle changer for the 6-segment Collect&Place head may be installed at location 2. It is set
up in place of the nozzle changer for the 12-segment Collect&Place head (item 1 in Fig. 6.1 - 2
,
page 263
). This gives a total capacity of 4 magazines with a total of 24 nozzle holders.
D2 placement machine 6
A nozzle changer for the 6-segment Collect&Place head may be installed at locations 1 and 2. It
is set up in place of the nozzle changer for the 12-segment Collect&Place head (item 1 in Fig. 6.1
- 3, page 264). This gives a total capacity of 2 nozzle changers with 8 magazines and a total of 48
nozzle holders.
Nozzle changer for the 6-segment Collect&Place head
Dimensions (length x width x height) 565 x 69 x 87 mm³
Number of magazines 4, each with 6 nozzle holders
Nozzle types 8xx, 9xx
Nozzle changeover time approx. 2s per nozzle
Compressed air connection 0.48 MPa (4.8 bar)
