1 Introduction User Manual SIPLACE D1/D2 1.5 Important notes on the user manual From software version SR.605.xx 07/2008 EN Edition 32 1.5.5.3 Document ation packages, Edition 0 7/2008 1 PLEASE NOTE 1 Further information …
User Manual SIPLACE D1/D2 1 Introduction
From software version SR.605.xx 07/2008 EN Edition 1.5 Important notes on the user manual
31
The various headings contain information on
– our products
– services
– contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– technical documentation
– technical information
– spare parts catalogs etc.
Registering for access to the User Group is sheer child’s play:
→ Click on ’Register now’.
→ Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
1 Introduction User Manual SIPLACE D1/D2
1.5 Important notes on the user manual From software version SR.605.xx 07/2008 EN Edition
32
1.5.5.3 Documentation packages, Edition 07/2008
1
PLEASE NOTE 1
Further information about the station extensions such as assembly, operation and preventive
maintenance described in Chapter 6 can be found on the SIPLACE homepage. 1
1
1.5.6 Abbreviations
1
Package contents Language
a
Item no.
DVD product documentation incl. parts catalogs
(PDF and HTML), in German and English
Detailed circuit diagrams folder in German/English
Operating instructions in the ordered language
version
Preventive maintenance in the ordered language
version
Software instructions: First Steps 605 in the ordered
language version
JobGuides / JobPoster
in the ordered language version
Angle gauge / tape gauge in the ordered language
version
German 00195835-01
English 00195836-01
French 00195837-01
Italian 00195838-01
Spanish 00195839-01
Portuguese 00195840-01
Hungarian 00195841-01
Czech 00195842-01
Russian 00195843-01
Polish 00195844-01
Estonian 00195845-01
Finnish 00195846-01
Swedish 00195847-01
Danish 00195848-01
Dutch 00195849-01
T. Chinese 00195850-01
S. Chinese 00195851-01
Korean 00195852-01
Japanese 00195853-01
a) Other language available on request
PA Placement area
CO Component
C&P Collect&Place
C&P12 Collect&Place head with 12 segments
User Manual SIPLACE D1/D2 1 Introduction
From software version SR.605.xx 07/2008 EN Edition 1.5 Important notes on the user manual
33
C&P6 Collect&Place head with 6 segments
DCA Direct chip attach
DC Dual conveyor
ESD Electrostatically-sensitive group of components
ESD Electrostatic sensitive device
SC Single conveyor
FC Flip chip
WT Waffle-pack tray
WTC Waffle-pack tray carrier
GND Ground
IC Integrated circuit
PCB Printed circuit board
MC Machine controller
OSC Odd shaped components
P&P Pick&Place
SM Dual conveyor in Single conveyor mode
SMD Surface mounted device
SC Station computer
VS Vision system
WLAN Wireless Local Area Network
WPC Waffle-pack changer
