User Manual SIPLACE D1/D2 6 Station extensions From software version SR.605.xx 07/2008 EN Edition 6.1 Nozzle changer 275 6.1.3 Nozzle changer for th e SIPLACE Pick&Place head Item no. 001 19817-xx Nozzle changer , P&…
6 Station extensions User Manual SIPLACE D1/D2
6.1 Nozzle changer From software version SR.605.xx 07/2008 EN Edition
274
→ First place the side of the magazine with the centering hole (item 3 in Fig. 6.1 - 9) and the slot
(item 4 in Fig. 6.1 - 9
) on the base. The two knobs on the magazine must slide into the retain-
ing clamp (item 2 in Fig. 6.1 - 9
).
→ Push the spring hook away from the magazine.
→ Press the magazine so that it lies flat on the base, then release the spring hook. The spring
hook must latch into place.
6.1.2.7 Position detection
Every magazine of the nozzle changer has a positioning fiducial for position detection.
6
Fig. 6.1 - 10 Nozzle changer - Position detection
(1) Positioning fiducial
(2) Position of the nozzles in the magazine relative to the positioning fiducial
User Manual SIPLACE D1/D2 6 Station extensions
From software version SR.605.xx 07/2008 EN Edition 6.1 Nozzle changer
275
6.1.3 Nozzle changer for the SIPLACE Pick&Place head
Item no. 00119817-xx Nozzle changer, P&P, D1
Item no. 03048676-xx Magazine for 2 nozzles
Item no. 03048639-xx Magazine for 1 nozzle
6.1.3.1 Description
This nozzle changer can hold up to 10 nozzle magazines. There are two types of magazine avail-
able: standard magazines and magazines for special nozzles or grippers. The magazines are
seated on a common support. They are centered with two parallel pins and fixed in place with two
countersunk screws.
Standard configuration: 2 magazines, each for two nozzles
1 magazine for special nozzles or grippers
6
Fig. 6.1 - 11 Nozzle changer for the SIPLACE P&P head
(1) Carrier
(2) Magazine for 2 nozzles
(3) Magazine for special nozzles or grippers
6
6
6 Station extensions User Manual SIPLACE D1/D2
6.1 Nozzle changer From software version SR.605.xx 07/2008 EN Edition
276
WARNING 6
Only install the associated nozzle changer for each placement head. There is a risk of head
crashes with mixed configurations.
6.1.3.2 Technical data
6
6
6
6
6
6
6
6.1.3.3 Position of the nozzle changer for the Pick&Place head on the D1 machine
One nozzle changer for the Pick&Place head may be installed at location 2 on the D1 machine.
Up to 10 magazines may be set up on the carrier. This gives a total capacity of up to 20 nozzle
holders.
Nozzle changer for the SIPLACE Pick&Place head
Dimensions (length x width x height) 192 x 138 x 314 mm³
Number of nozzle holders 20 for standard nozzles
10 for special nozzles or grippers
Nozzle types 5xx, standard
4xx with adapter
8xx with adapter
9xx with adapter
Nozzle changeover time approx. 2s per nozzle
