User Manual SIPLACE D1/D2 2 Operational safety From software version SR.605.xx 07/2008 EN Edition 2.2 Warning labels 47 2.2.3.1 W arning label W205 on the transverse bar below the t ape cutter 2 Fig. 2.2 - 4 Warning labe…
2 Operational safety User Manual SIPLACE D1/D2
2.2 Warning labels From software version SR.605.xx 07/2008 EN Edition
46
WARNING 2
Powerful permanent magnetic fields inside the machine
DANGER 2
Risk of death for persons with active implants (e.g. pacemakers, insulin pumps, defibrillators).
2
WARNING
Danger of crushing for persons with passive metal implants (e.g. plates, screws).
Do not reach into the machine or bend towards it when the protective covers are open.
Do not bring any metal objects into the area.
2.2.3 Warning labels on tape cutter and used tape chute
2
Pos. W205 in Figs. 2.2 - 5 and 2.2 - 4, item no. 03009344-01
WARNING 2
If you wish to do work on the tape cutter, you must disconnect the machine from the mains sup-
ply and the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Wear robust protective gloves when working on the tape cutter.
2
2
2
2
2
2
2
2
RISK OF CUTTING!
Danger of cutting is present even when the machine is
switched off
User Manual SIPLACE D1/D2 2 Operational safety
From software version SR.605.xx 07/2008 EN Edition 2.2 Warning labels
47
2.2.3.1 Warning label W205 on the transverse bar below the tape cutter
2
Fig. 2.2 - 4 Warning label W205 on the transverse bar below the tape cutter
(2) Tape cutter
(3) Used tape channel
(4) Used tape chute
Pos. W205, item no. 03009344-01 on the transverse bars (number per machine: 2)
2 Operational safety User Manual SIPLACE D1/D2
2.2 Warning labels From software version SR.605.xx 07/2008 EN Edition
48
2.2.3.2 Warning label W205 on the used tape chute
2
Fig. 2.2 - 5 Warning label W205 on the used tape chute
Pos. W205, item no. 03009344-01 on the used tape chute (number per machine: 2)
The position of the used tape chute is shown in Fig. 2.2 - 4
, item 3 on page 47.
